API 6D Floating Ball Valves, A182 F316L, 1 Inch, 600 LB, RF

The API 6D Floating Ball Valves Factory produces high-performance ball valves made from forged stainless steel (ASTM A182 F316L). These valves feature a 1-inch (DN25) diameter and are rated at Class 600 LB, ensuring robustness and reliability. They are designed with raised face (RF) flanged ends for secure connections and are operated using a lever, providing easy control. Suitable for demanding industrial applications, these valves meet API 6D standards, ensuring quality and safety.

Product Name: ASTM A182 F316L Floating Ball Valve, Forged
Type: Floating Ball Valve
Design Standard: API 6D
Body Material: ASTM A182 F316L
Size: 1 Inch, DN25
Pressure: Class 600 LB, PN100
End Connection: RF
Operation: Lever
Temperature Range: -46°C to 120°C
Medium: Water, Gas, Oil, etc.

Forged Floating Ball Valves are engineered with a design that supports the ball using two PTFE seats, one upstream and one downstream. The upstream line pressure pushes the ball against the downstream seat, ensuring a tight shutoff for efficient fluid control. All cast floating ball valves are manufactured using high-quality castings and certified fire-safe designs in accordance with BS 6755, API 607, and API 6FA, meeting all applicable ASME standards. These valves are available in One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body configurations. Designed and manufactured to the latest international standards, including API 6D, ASME B16.34, and BS 5351, they feature fire-safe construction, anti-static components, and blowout-proof stem design.

Technical Specifications

» Type: Forged Floating Ball Valve
» Size Range: NPS 1/2-10 Inch (DN15-DN250)
» Pressure Rating: Class 150-1500 LB (PN10-PN250)
» Body Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Special Alloys
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and others
» Seat Materials: NYLON, RPTFE, PEEK
» End Connections: Flat Face (FF), Raised Face (RF) Flanges, Butt Welded
» Operation Options: Lever Handle, Worm Gear, Electric, Pneumatic
» Design Standards: API 6D, BS 5351, ASME B16.34
» Face-to-Face: ASME B16.10
» Flange Standards: ASME B16.5
» Butt Weld End: ASME B16.25
» Testing and Inspection: API 598, API 6D
» Fire Safety Certifications: API 607, API 6FA

Product Features

» Low Operating Torque
» Emergency Sealing System
» Fire-Safe Structure Design
» Anti-Static Device
» Reliable Seat Sealing Mechanism
» Automatic Pressure Relief Structure (Upstream Side)
» Blowout-Proof Stem with Flyout Prevention Design
» Excellent Corrosion and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional ISO 5211 Direct Mounting Pad
» Available in Full Port or Reduced Bore Designs
