2 Piece Floating Ball Valve, API 6D, ASTM A105, 1 IN, CL1500

Name: 2 Piece Floating Ball Valve, API 6D, ASTM A105, 1 IN, CL1500
SKU: KV-20250210-FBV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 2 Piece Floating Ball Valve features a forged carbon steel body designed for durability and reliability. It complies with API 6D standards and has a 1-inch size (DN25), with a Class 1500 LB pressure rating and PN250. The valve is lever-operated and equipped with RTJ flanged ends, ensuring easy installation and secure sealing in high-pressure applications.

Request a quote

Detail Information

Product Name: 2 PC Forged Floating Ball Valve
Design Standard: API 6D
Body Material: ASTM A105
Size: 1 Inch, DN25
Pressure: Class 1500 LB, PN250
End Connection: RTJ
Operation: Lever

Forged Floating Ball Valve features a design that supports the ball with two PTFE seats—one on the upstream side and the other on the downstream side. The upstream pressure pushes the ball against the downstream seat, ensuring a complete shutoff for reliable fluid control.
All our Cast Floating Ball Valves are manufactured with high-quality castings and incorporate a fire-safe design, certified in accordance with BS 6755, API 607, and API 6FA. These valves comply with all applicable ASME standards.
Floating Ball Valves are available in three types: One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body. They are designed and manufactured to meet the latest international standards, including API 6D, ASME B16.34, and BS 5351 or their equivalents. Standard features include Fire-Safe, Anti-Static, and Blowout-Proof design, ensuring durability and safety in demanding applications.

Technical Specifications

» Size Range: NPS 1/2-10 Inch (DN15-DN250)
» Design Pressure: Class 150-1500 LB (PN10-PN250)
» Materials: Forged Carbon Steel, Stainless Steel, Duplex Steel, or other special materials (ASTM A105N, A350 LF2, A182 F11, F22, F304, F304L, F316, F316L)
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» Seat Materials: Nylon, RPTFE, PEEK
» End Connections: RF and RTJ flange, welded
» Operation: Handle, worm gear, electric, pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face-to-Face (End-to-End): ASME B16.10
» Flanged Connection: ASME B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A
» Temperature Range: -46°C to 120°C

Product Features

» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structure Design
» Anti-static Structure
» Reliable Seat Sealing
» Automatic Pressure Relief for Upstream
» Blow-out Proof Stem
» Corrosion & Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» ISO 5211 Direct Mounting Option
» Full Port or Reduced Bore
