ASTM A351 CF8 Trunnion Ball Valve, API 6D, 8 IN, 600 LB, RF

Product Name: Stainless Steel Trunnion Ball Valve
Design Standard: API 6D
Body Material: ASTM A351 CF8
Size: 8 Inch, DN200
Pressure: Class 600 LB, PN100
End Connection: RF
Operation: Gearbox

Trunnion Mounted Ball Valves are designed for smooth and efficient operation under high line pressure. These valves feature carefully aligned bearings that ensure low torque operation. The ball is fixed in position but remains free to rotate, providing reliable performance. All Cast Trunnion Ball Valves are constructed with high-quality castings and are fire-safe, meeting certifications such as BS 6755, API 607, and API 6FA, along with all applicable ASME standards. Available in Two-Piece Split Body and Three-Piece Bolted Body configurations, these valves are engineered to meet the latest international standards, including API 6D, ASME B16.34, and BS 5351. Key features include Fire Safe, Anti-static, and Blow-out Proof Stem designs.

Technical Specifications

» Size Range: NPS 2-48 Inch (DN50-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: Cast Carbon Steel, Stainless Steel, Duplex Steel, ASTM A216 WCB, WCC, A352 LCB, LCC, A351 CF8, CF8M, CF3, CF3M
» Trim Materials: 13% Cr, SS 304, SS 304L, SS 316, SS 316L
» Seat Materials: RPTFE, DEVLON, PEEK
» End Connections: Flanged RF, RTJ, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Temperature Range: -46°C to 120°C
» Medium: Water, Gas, Oil, etc.
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face-to-Face (End-to-End): ASME B16.10
» Flanged Connections: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A

Product Features

» Double Block and Bleed (DBB)
» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structure Design
» Anti-static Structure
» Reliable Seat Sealing Structure
» Single Sealing (Automatic Pressure Relief in Middle Cavity)
» Double Sealing (Double Piston)
» Safety Relief Device
» Special Structure of Automatic Pressure Relief Towards Upstream
» Blow-out Proof Stem
» Corrosion Resistance and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Full Port or Reduced Bore
