ASTM A351 CF8 Knife Gate Valve, DN100, PN10, 4 Inch, Wafer

Product Name: ASTM A351 CF8 Knife Gate Valve, Bidirectional
Body Material: ASTM A351 CF8
Size: DN100, 4 Inch
Pressure: PN10, Class 150 LB
End Connection: Wafer
Operation: Manual

The Bidirectional Knife Gate Valve is designed for reliable shutoff and efficient flow control in both directions. Its maintenance-free compact cross seal, with a double seal lip profile, ensures a tight shutoff, adjustable without interrupting operations. The valve features a self-cleaning effect with flush-out corners in the body and a cutting edge underneath the gate, allowing solids and fibers to be cut before sealing. The lateral gate surfaces and elastic seat provide bidirectional shutoff, while the high finish of the guide and sealing surface ensures long service life and tight shutoff. The gate’s lateral guidance prevents fluttering, even in throttle positions.

Technical Specifications

» Structure: Bidirectional Knife Gate Valve
» Nominal Diameter: NPS 2-16 Inch (DN50-DN400)
» Design Pressure: PN10, PN16, Class 150 LB
» Temperature Range: -29°C to 120°C
» Max Working Pressure:
   DN50-DN250: 10 bar
   DN300-DN450: 7 bar
   DN500-DN600: 4 bar
» Body Material: GGG40, ASTM A351 CF8, CF8M, Special Alloys
» Disc Material: Stainless Steel Chrome Plated, Special Alloys
» Seat Material: EPDM (120°C), NBR (80°C)
» Flange Standards: GB/T 9113.1, JB/T 79.1, HG 20592, ASME B16.5, EN 1092-1
» Face to Face: MSS SP-81
» Operation: Manual, Pneumatic, Electric, Hydraulic
» Ends Connections: Wafer Type


Product Features

» Bidirectional
» Split Body
» Flatness knife
» Light torque
» Support yoke
» Epoxy coating-Fusion bonded paint
» Sealing type
