ASTM Material Specifications for Your Reference

KOSEN Valves: Reference of ASTM Material Specifications
Covering Cast and Forged Valves, Fittings, Flanges and Unions
Material	Forgings	Castings	Wrought Fittings
Carbon Steel Cold Temperature Service	A105 A350-LF2	A216 WCB	A234 WPB A420-WPL6
Carbon-1/2 Moly Alloy Steel High Temperature Service	A182-F1	A217-WC 1 A352-LC1	A234-WP1
3-1/2 Nickel Alloy Steel Low Temperature Service	A350-LF3	A352-LC3	A420-WPL3
1/2 Cr-1/2 Mo Alloy Steel 1/2 Cr-1/2 Mo-1 Ni Alloy 3/4 Cr-1 Mo-3/4 Ni Alloy Steel 1 Cr-1/2 Mo Alloy Steel	A182-F2 A182-F12 CL2	A217-WC4 A217-WC5	A234-WP12 CL2
1-1/4 Cr-1/2 Mo Alloy Steel 2-1/4 Cr-1 Mo Alloy Steel 5 Cr-1/2 Mo Alloy Steel 5 Cr-1/2 Mo Alloy Steel 9 Cr-1 Mo Alloy Steel 13 Cr Alloy Steel	A182-F11 CL2 A182-F22 CL 3 A182-F5 A182-F5a A182-F9 A182-F6	A217-WC6 A217-WC9 A217-C5 A217-C12 A743-CA15	A234-WP11 CL2 A234-WP22 CL 3 A234-WP5 A234-WP9
Type 304 Stainless Steel (18 Cr-8 Ni) Standard Low Carbon High Temperature Service	A182-F304 A182-F304L A182-F304H	A351-CF3 A351-CF8	A403-WP304 A403-WP304L A403-WP304H
Type 310 Stainless Steel (25 Cr-20 Ni) Type 316 Stainless Steel (16 Cr-12 Ni-2 Mo) Standard Low Carbon High Temperature	A182-F310H A182-F316 A182-F316L A182-F316H	A351-CK20 A351-CF3M A351-CF8M	A403-WP310 A403-WP316 A403-WP316L A403-WP316H
Type 317 Stainless Steel (18 Cr-13 Ni-3 Mo) Type 321 Stainless Steel (18 Cr-10 Ni-Ti) Standard High Temperature Service	A182-F321 A182-F321H		A403-WP317 A403-WP321 A403-WP321H
Type 347 Stainless Steel (18 Cr-10 Ni-Cb) Standard High Temperature Service	A182-F347 A182-F321H	A351-CF8C	A403-WP347 A403-WP347H
Type 348 Stainless Steel (18 Cr-10 Ni-Cb) Standard High Temperature Service	A182-F348 A182-F348H		A403-WP348 A403-WP438H

API Trim Materials
Trim Number	Seat Ring Surface	Wedge Seat Surface	Stem	Backseat Bushing
1	A182 F6	A182 F6	A182 F6	A182 F6
2	A182 F304	A182 F304	A182 F304	A182 F304
5	Stellite	Stellite	A182 F6	A182 F6
6	Cu-Ni	A182 F6	A182 F6	A182 F6
8	Hardfaced	A182 F6	A182 F6	A182 F6
9	Monel	Monel	Monel	Monel
10	A182 F316	A182 F316	A182 F316	A182 F316
12	A182 F316/HF	A182 F316/HF	A182 F316	A182 F316
13	A20	A20	A20	A20
18	Stellite	A182 F6	A182 F6	A182 F6
