BS 1873 Globe Valves, A216 WCB, 3 IN, CL300, Parabolic Disc

Product Name: Cast Steel Globe Valve with Parabolic Disc
Design Standard: BS 1873
Body Material: ASTM A216 WCB
Size: 3 Inch, DN80
Pressure: Class 300 LB, PN50
End Connection: Flanged
Operation: Manual

Cast Steel Globe Valves are engineered and manufactured to achieve a leakage rate of less than 100 ppm (parts per million) of volatile organic compounds (VOCs). Extensive baseline laboratory testing, including both static and cycle testing, has been conducted to establish the critical design parameters necessary for achieving low emission sealing. These tests specifically focus on the KOSEN stem packing seal area and the bonnet gasket sealing area. An in-house testing procedure has been developed and is regularly performed to ensure that the product's design and manufacturing standards consistently result in Cast Steel Globe Valves meeting the strict 100 ppm VOC leakage threshold prior to shipment.

Technical Specifications

» Nominal Diameter: NPS 1/2–24 Inch (DN15–DN600)
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3M, CF8C, CN3MN, CK3MCUN, CN7M, A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN), B148 C95800, C95500
» End Connections: Flanged (FF, RF, RTJ) and BW to international standards
» Operation: Handwheel, bevel gear, electric, pneumatic
» Applications: Electric power, petroleum refining, petrochemical engineering, offshore oil, urban water engineering, chemical engineering
» Design and Manufacture: ASME B16.34, BS 1873, DIN 3356
» Face to Face (End to End): ANSI B16.10, EN 558 series
» Flanged Connection: ANSI B16.5, EN 1092 series
» Butt Welded End: ANSI B16.25
» Test and Inspection: API 598, ISO 5208, EN 12266-1
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, and other fluids

Product Features

» OS&Y (Outside Stem and Yoke) design with a bolted bonnet and rising stem for reliable operation.
» Short stroke for quick and easy valve opening and closing.
» Suitable for large sizes and high-pressure applications, featuring a relief cone with an internal bypass.
» Disc sealing options include flat sealing or throttle cone for regulating disc applications.
» Body seat options include threaded or welded seats to suit various installation requirements.
» Metal-sealed options available, including API Trim #1, #5, #8, #10, and others.
» Optional locking device for added security and stem extension for easier operation.
» Optional direct mounting to ISO 5211 standards for actuator compatibility.
» Reduce port configuration for specific flow control needs.
