ASME B16.34 Globe Valves, BS 1873, A216 WCB, 4 Inch, 300 LB

The ASME B16.34 Globe Valves Factory in China produces high-quality globe valves adhering to BS 1873 standards. These valves are made from cast carbon steel ASTM A216 WCB, ensuring durability and reliability. The 4-inch (DN100) valves are rated for Class 300 LB (PN50) and feature RF flanged ends for secure and easy connections. They are manually operated, providing precise control over fluid flow.

Product Name: ASTM A216 WCB Globe Valve
Design Standard: ASME B16.34, BS 1873
Body Material: ASTM A216 WCB
Size: 4 Inch, DN100
Pressure: Class 300 LB, PN50
End Connection: RF
Operation: Manual

Cast Steel Globe Valves are designed and manufactured to ensure leakage of less than 100 ppm (parts per million) of volatile organic compounds (VOCs). Extensive baseline laboratory testing, including static and cycle testing, has been conducted to establish the critical design parameters necessary to achieve low emission sealing in the stem packing seal area and bonnet gasket sealing area. An in-house testing procedure has been developed and is periodically performed to ensure that the standard product design and manufacturing criteria consistently result in Cast Steel Globe Valves meeting a maximum VOC leakage of 100 ppm prior to shipment.

Technical Specifications

» Nominal Diameter: NPS 1/2–24 Inch (DN15–DN600)
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3M, CF8C, CN3MN, CK3MCUN, CN7M, A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN), B148 C95800, C95500
» End Connections: Flanged (FF, RF, RTJ) and BW to international standards
» Operation: Handwheel, bevel gear, electric, pneumatic
» Applications: Electric power, petroleum refining, petrochemical engineering, offshore oil, urban water engineering, chemical engineering
» Design and Manufacture: ASME B16.34, BS 1873, DIN 3356
» Face to Face (End to End): ANSI B16.10, EN 558 series
» Flanged Connection: ANSI B16.5, EN 1092 series
» Butt Welded End: ANSI B16.25
» Test and Inspection: API 598, ISO 5208, EN 12266-1
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, and other fluids

Product Features

» OS&Y: Bolted bonnet, rising stem design.
» Short Stroke: Facilitates easy and quick open/close operation.
» For Large Sizes and High Pressure: Relief cone with internal bypass.
» Disc Sealing: Options include flat sealing and throttle cone for regulating disc.
» Body Seat Options: Threaded seat or welded seat.
» OS&Y (Outside Stem and Yoke): External stem and yoke design.
» Metal-Sealed: Available with API Trim #1, #5, #8, #10, etc.
» Optional Locking Device or Stem Extension: Provides additional security and flexibility.
» Optional Direct Mounting to ISO 5211: Allows for direct actuator mounting.
» Reduced Port: Offers reduced flow capacity for specific applications.
