PM2.5 TVOC CO2 All In One Air Quality Detection Sensor

Oct 12, 2022

High Air Quality PM2.5 VOC CO2 All-In One Detection Module, Temperature and Humidity Sensor

Model Number: MM201A
Type: Air quality sensor, CO2 sensor, Gas Sensor, Humidity Sensor
Usage: Intelligence appliance, air quality monitoring, Environmental Monitoring
Theory: Laser scattering and semiconductor technology, NDIR
Output: UART TTL
Description: All-in-one air quality inspection module
Measuring range: 0-1000ug/m3
Power supply: DC 5±0.5V
Size: 69 mm * 51.5 mm * 18mm
Features: High Precision
Certificate: ROHS, REACH, ISO 9001
Response time: ≤4s
Temperature range: -20°C-60°C
Supply Ability: 5000 Piece/Pieces per Day
Packaging Details: 70PCS/layer, 6 layers per box, 420PCS in total

Parameter	Index
Measuring parameters	PM2.5	CO2	TVOC
Measuring range	0～600ug/m³	400～5000ppm	0～9.999mg/m³
Measuring precision	≥100ug/m³:±10%; <100ug/m³:±10ug/m³	±（50ppm+5% of reading）	Output resolution 0.001mg/m³.
Resolution	1ug/m³	1ppm	0.001mg/m³
Warm-up time/ turn-on stabilizing time	Turn-on stabilizing time ≤4s	Turn-on stabilizing time≤ 30s	Warm-up time≤3min
Recovery time	Heal Instantly	Heal Instantly	< 60s
Response Time	≤4s	/	T90 <20s
Temperature	Accuracy:±1.5°C; Resolution:0.1°C
Humidity	Accuracy:±5%RH; Resolution：0.1%RH
Data interface	UART TTL, 9600bps
Power voltage	DC 5±0.5V，Ripple <100mV
Working current	200mA
Working conditions	Temperature: 0-50°C; humidity: 15-90% RH（non-condensing）.
Storage conditions	Temperature: -20°C-60°C; humidity: 15-90%RH（non-condensing.
SIZE	69 mm * 51.5 mm * 18mm
