PM2.5 PM10 TVOC CO2 Formaldehyde Temperature Humidity Sensor
Key Specifications / Features
We Provide PM2.5 PM10 TVOC CO2 Formaldehyde Temperature Detectors, All-in-one Integrated Air Quality Detection Module, PM 1.0, PM2.5, CO2, TVOC, Humiture.
Detail Information
PM2.5 PM10 TVOC CO2 Formaldehyde temperature humidity sensor, all in one integrated air quality detection module
Specification: PM 1.0, PM2.5, CO2, TVOC, humiture
Model Number: MM201
Type: CO2 sensor, Air quality sensor, Gas Sensor, Humidity Sensor
Usage: intelligence appliance, air quality monitoring, Environmental Monitoring
Theory: laser scattering and semiconductor technology, NDIR
Output: UART TTL, UART TTL
Description: All-in-one air quality inspection module
Measuring range: 0-1000ug/m3
Power supply: DC 5±0.5V
Size: 69 mm * 51.5 mm * 18mm
Features: High Precision
Certificate: ROHS, REACH, ISO 9001
Response time: ≤4s
Temperature range: -20°C - 60°C
Supply Ability: 5000 Piece/Pieces per Day
Packaging Details: 70 PCS/layer, 6 layers per box, 420 PCS in total
| Parameter | Index | ||
| Measuring parameters | PM2.5 | CO2 | TVOC |
| Measuring range | 0-600ug/m³ | 400-5000ppm | 0-9.999mg/m³ |
| Measuring precision | ≥100ug/m³:±10%; <100ug/m³:±10ug/m³ |
±（50ppm+5% of reading） |
Output resolution 0.001mg/m³. |
| Resolution | 1ug/m³ | 1ppm | 0.001mg/m³ |
| Warm-up time/ turn-on stabilizing time | Turn-on stabilizing time ≤4s | Turn-on stabilizing time≤ 30s | Warm-up time≤3min |
| Recovery time | Heal Instantly | Heal Instantly | < 60s |
| Response Time | ≤4s | / | T90 <20s |
| Temperature | Accuracy: ±1.5°C; Resolution: 0.1°C | ||
| Humidity | Accuracy: ±5%RH; Resolution: 0.1% RH | ||
| Data interface | UART TTL, 9600bps | ||
| Power voltage | DC 5±0.5V，Ripple <100mV | ||
| Working current | 200mA | ||
| Working conditions | Temperature: 0-50°C; humidity: 15-90% RH (non-condensing) | ||
| Storage conditions | Temperature: -20°C-60°C; humidity: 15-90% RH (non-condensing) | ||
| SIZE | 69 mm * 51.5 mm * 18mm | ||
