Wire Circuit Analyzer NF-8208R

Oct 26, 2012

Main Functions :
♦One person enough to complete cable continuity check.
♦The function of probing the audio and tracing the cable.
♦Check wire fault in 5E, 6E, coaxial and telephone line such asopen , short , jumper wire, reverse connection or cross-talkinterference.
♦Locate the range of wire or connection error .
♦Measure cable length and determine the distance of open andshort circuit.
♦Dynamically calibrate cable length and make length measurement asaccurate as 95%.
♦Far-end recognizer with prompting voice.
♦Self-checking function and automatically compensate any change inbattery capacity or ambient temperature.
♦Single board computer software watchdog design and reliable operation.
Technical indexes:

Overall dimension	Main tester: 180×80×40mm; receiver: 218×46×29mm; Remote identifier: 77×31×21mm.
Power	Main tester: 6V DC battery. Receiver: 9V DC battery.
Display	4 x 16 character big screen LCD lattice (valid visual field 61.6 x 25.2 mm).
tested cables	STP/UTP twin twisted cable, coaxial cable, telephone line.
detected lines	5E, 6E, telephone wire, coaxial cable and other metal wires.
Ambient temperature of work	-10℃~+60℃
Tester Port	Tester RJ45 master port (M), tester LOOPBACK RJ45 port (L), hunting RJ45 port(SCAN); Remote identifier RJ45 port (R); The extra BNC and RJ11 converters (to measure and check the continuity of coaxial cable and telephone line).
Length Measurement of Twin Twisted Cable	Scope: 1~350 M (3 ~200 ft) Calibration accuracy: 3% (+/- 0.5M or +/- 1.5 ft) (calibrating cable > 5 M) Shipment accuracy: 5% (+/- 0.5 M or +/- 1.5 ft). (AMP, AT&T Class 5 cable)
Length Calibration	User can set calibration factor by himself with a given length cable. The length of cable is more than 5M.
