Wire Rod Coil Shot Blasting Machine

Main Structure and Technical Parameters
The Wire Coil Shot Blasting Machine is Mainly Consisted of Shot Blast Cleaning Room, Work Piece Supporting System, Abrasive Recovery System, Dust Remover System, Electric Control System, etc.

Technology Parameter(Customized is available):

Range of work piece	Wire rod diameter ≤ 2000mm,
Working efficiency	6-12min/batch, Wire rod's weight per batch  ≤ 3000kg
Mandrel rotational speed	3~10r/min
Shot blasting turbine qty	6 sets
Shot blasting turbine power	18.5,22,or 37 kW/set
Bucket elevator	11kW*2sets
Dust remover fan	22kW
Total power	170kW ~ 230kW

This machine is not a standard machine, any parameters can be customized according clients' requirements, so any further information please contact with us, our skilled engineer team will give you the most professional and cost-effective solutions.

Machine Details:


These Type of Machines consist of under mentioned Parts:
1. Main Blast Cabinet with inspection Door
2. Blast Wheel Units with Drive Mechanism.
3. Abrasive circulation unit
4. Bucket Elevator unit
5. Abrasive Separation/Cleaning system with Storage Hopper
6. Dust Collector with Cleaning Mechanism.
7. Roller Conveyor system at Inlet & Outlet Side.
8. Control Panel with PLC Control System.


JX Shot Blasting Machine offers upgraded transport technology, high-efficient blast wheels and multiple machine sizes and types adhere to the customer's shot-blasting needs. If you have special requirements, please download Blasting Equipments Questionnaire for your reference.
