EN 1984 Gate Valve, WCB, DN200, PN63, 8 Inch, 400 LB, BB, RF

Feb 09, 2023

DN200 PN63 Cast Steel Gate Valve HW-OP OS&Y BB RF

Introduction

DN200 PN63 gate valve is made according to EN 1984 standards. The valve body is made of ASTM A216 WCB+STL. It has the structural characteristics of Bolt cover, rising stem and support. Its connection mode is RF. And it has hand wheel operation mode.

Features

1. The fluid resistance is small, and the sealing surface is little scoured and eroded by the medium;
2. The flow direction of the medium is not restricted, the flow is not disturbed, and the pressure is not reduced;
3. Simple structure, short structure length, good manufacturing process, high temperature and high-pressure resistance, many optional materials, wide application range.

Technical Drawing
