BS EN 1984 Gate Valve, DN200, PN16, WCB, DIN 3202, RF

Name: BS EN 1984 Gate Valve, DN200, PN16, WCB, DIN 3202, RF
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Shop BS EN 1984 gate valve from a trusted manufacturer. Made of ASTM A216 WCB carbon steel, this 8-inch valve is designed for Class 150 LB applications. It has a DN200 size and PN16 pressure rating, conforming to DIN 3202 standards. Featuring a bolted bonnet and raised flanged ends, this gate valve is reliable and efficient. Order now for high-quality industrial valves.

Request a quote

Detail Information

Gate valve, carbon steel, bolted bonnet, DN200, PN16, WCB, RF.

Valve description:
Gate valve, bolted bonnet, Raised flange, BS EN 1984, DIN 3202.
Design: BS EN 1984.
Body: ASTM A216 WCB
Nominal size: DN200.
Nominal class: PN16.
End Connection: Raised flange.
Face to face: DIN 3202-F5.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Gate valve.
Nominal diameter	1/2 Inch - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	BS EN 1984.
Face to face	DIN3202-F5.
Connection end	BW, Flange.
Test standard	BS EN12266.
Package	Plywood
Application	The oil and gas industry
Special test	Impact test.
