Dual Port DC EV Fast Charging Station, 360kW, OCPP1.6J, IP54
360kW DC EV Charging Station, OCPP 1.6J, IP54, 380/400V AC.
Rated Power: 360kW
OCPP: OCPP1.6J
DC Connectors: Dual DC Connectors(GBT + GBT),(GBT + CCS2)
Input Voltage: 380/400V AC ±10%
Input Frequency: 50/60 Hz
IP Protection: IP54
Output Current: 0-250A (GBT), 0-200A (CCS1 & CCS2)
Output Voltage: 200-1000V DC
System Efficiency: Full Load≥94%
Power Factor: ≥0.99
Harmonic Current: ≤3% (under rated operation condition)
Output Current Accuracy: ≤±0.5%
Output Voltage Accuracy: ≤±0.5%
Grounding Detection: ≤30mA
Protection: Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection.
Cable Length: 5 Meter
Communication Interface: 4G, RS485, CAN, ETHERNET
Noise: ≤65dB (norminal input/output power, the environment temperature is 25°C)
Operating Temperature: -40°C - +50°C
Cooling Method: Forced Air Cooling
Rated Power: 360kW
OCPP: OCPP1.6J
DC Connectors: Dual DC Connectors(GBT + GBT),(GBT + CCS2)
Input Voltage: 380/400V AC ±10%
Input Frequency: 50/60 Hz
IP Protection: IP54
Output Current: 0-250A (GBT), 0-200A (CCS1 & CCS2)
Output Voltage: 200-1000V DC
System Efficiency: Full Load≥94%
Power Factor: ≥0.99
Harmonic Current: ≤3% (under rated operation condition)
Output Current Accuracy: ≤±0.5%
Output Voltage Accuracy: ≤±0.5%
Grounding Detection: ≤30mA
Protection: Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection.
Cable Length: 5 Meter
Communication Interface: 4G, RS485, CAN, ETHERNET
Noise: ≤65dB (norminal input/output power, the environment temperature is 25°C)
Operating Temperature: -40°C - +50°C
Cooling Method: Forced Air Cooling
