Cummins Silent Diesel Generator Set, 200kW, 60 Hz, NT855-GA

Mar 27, 2025

Product Name: 200kW 250kVA Cummins Silent Diesel Generator Set
Fuel Type: Diesel
Engine: Cummins NT855-GA
Alternator: Stamford UCI274H
Rated Power: 200kW, 250kVA
Max. Power: 220kW, 275kVA
Frequency: 60 Hz
Rated Voltage: 220/127 V
Rated Current: 656.1 A
Noise Level: 70 dBA at 7m Away
Dimensions (L*W*H): 3200*1500*2010 mm
Net Weight: 2350 kg

Cummins Diesel Engine Specifications (NT855-GA)

Engine Brand	Cummins
Engine Model	NT855-GA
Number of Cylinders	6 (Inline)
Aspiration	Turbocharged
Governor Type	Electric
Max. Engine Output Power	254 kW
Displacement	14.0 L
Starting Voltage	24 V
Bore × Stroke	140 mm × 152 mm
Lubrication Oil Capacity	38.6 L

Stamford Alternator Specifications (UCI274H)

Alternator Brand	Stamford
Alternator Model	UCI274H
Rated Output	255kVA
Frequency	60 Hz
Insulation Class	Class H
Altitude (Standard)	≤1000 m
Voltage Regulation	AVR Model SX460
Protection Grade	IP23
Optional Alternators	Leroy Somer, Marathon, Mecc Alte

Control Panel Specifications

Controller Brand	Deepsea
Controller Model	DSE7320
Breaker Brand	Delixi
Breaker Capacity	80 A
Battery Charger	Smartgen Model BAC06A
Emergency Stop Button	Yes
Automatic Mains Failure (AMF)	Yes
Fuel Level Indicator	Yes
Automatic Transfer Switch (ATS)	Optional
