Bucket Wheel Stacker Reclaimer for Bulk Materials Handling
Key Specifications / Features
China bucket wheel stacker reclaimer supplier offers bucket wheel stacker reclaimer combining stacking and reclaiming tasks in bulk material handling.
Request a quote
Detail Information
Bucket wheel stacker reclaimer is a high-efficiency loading and unloading machine used for large-scale dry bulk yards for continuously stacking and reclaiming. It consists of a conveying arm with a bucket wheel on the arm front which can luff and slew so as to accomplish target stacking and reclaiming. The material transporting direction can be operated in stacking or reclaiming mold. When the material is reclaimed, the bucket wheel takes the material and sends it out through the conveying arm. When the material is stacked, the bulk material is transferred by the conveying arm. The bucket wheel stacker and reclaimer is used in longitudinal storage in coal and ore stockyards for fields such as power, metallurgy, coal, building material and chemical industries. Its features and benefits include large slewing radius, high productivity, low power consumption and optimal environment protection solutions.
Basic Structure
Bucket-wheel structure, cantilever belt conveyor, metal structure, rotary table, gate seat, slewing mechanism, tripper car, accessory structure, rail system, lubrication system, control room
Technical Characteristics
1.Perfect homogenization
In the longitudinal material blending yard, different stacking processes can be adopted according to different working conditions. Continuous synthetic stacking methods can be adopted to ensure the homogenization effect in the circular material blending yard.
2. Reliability
2.1 We guarantee the advanced technology and stable equipment with the experience and development of making stackers and reclaimers as well as absorbing the advanced technology from international.
2.2 Advanced production equipment and manufacturing technique, such as steel pretreatment line which improves the product's quality and anti-corrosion capability, large milling and boring machine which improves the quality of large parts, large-scale structural components processed the pre-assembling procedure driving parts. Every equipment will be tested before delivery. Rotating parts are all processing mold integrated manufacturing.
2.3 New materials applicating, such as wear-resistance material, composite material
2.4 First class quality fittings
2.5 Damage reduced by soft start and frequency converting control
2.6 Protection programs are presetting
2.7 Advanced testing methods and QC system in our plant
3. Advancement
3.1 Fully automatic operation
3.2 Various stacking and reclaiming methods presetting to satisfy different work condition of blending yard
3.3 Advanced frequency conversion technical
Specification
Basic Structure
Bucket-wheel structure, cantilever belt conveyor, metal structure, rotary table, gate seat, slewing mechanism, tripper car, accessory structure, rail system, lubrication system, control room
Technical Characteristics
1.Perfect homogenization
In the longitudinal material blending yard, different stacking processes can be adopted according to different working conditions. Continuous synthetic stacking methods can be adopted to ensure the homogenization effect in the circular material blending yard.
2. Reliability
2.1 We guarantee the advanced technology and stable equipment with the experience and development of making stackers and reclaimers as well as absorbing the advanced technology from international.
2.2 Advanced production equipment and manufacturing technique, such as steel pretreatment line which improves the product's quality and anti-corrosion capability, large milling and boring machine which improves the quality of large parts, large-scale structural components processed the pre-assembling procedure driving parts. Every equipment will be tested before delivery. Rotating parts are all processing mold integrated manufacturing.
2.3 New materials applicating, such as wear-resistance material, composite material
2.4 First class quality fittings
2.5 Damage reduced by soft start and frequency converting control
2.6 Protection programs are presetting
2.7 Advanced testing methods and QC system in our plant
3. Advancement
3.1 Fully automatic operation
3.2 Various stacking and reclaiming methods presetting to satisfy different work condition of blending yard
3.3 Advanced frequency conversion technical
Specification
| Fixed Single Tripper Car Cantilever Bucket Wheel Stacker-Reclaimer | ||||||
| Conveying Material | Stacking Ability(t/h) | Feeding Ability(t/h) | Material Proportion(t/m3) | Material Granularity(mm) | Turning Radius(m) | Rail Gauge(m) |
| coal | 600 | 600 | 0.85-1 | 0-50 | 25 | 5 |
| coal | 1200 | 1000 | 0.8 | 0-50 | 30 | 6 |
| coal, lump ore | 1200 | 800 | 1.8-1.9 | 0-50 | 33 | 7 |
| coal, iron ore concentrate | 1250 | 800 | 1.85-1 | 0-50 | 35 | 7 |
| coal, lump ore | 1200 | 900 | 0.8 | 0-50 | 41 | 8 |
| iron ore | 1800 | 800 | 2.2-2.6 | 0-50 | 35 | 7 |
| iron ore | 3000 | 1500 | 2.2 | 20-120 | 38 | 8 |
| iron ore powder, pellet | 1500 | 1500 | 2.2 | 0-40 | 45 | 8 |
| coke, pellet | 1200 | 100 | 0.5-2.2 | 6-75 | 36 | 7 |
| sinter | 1050 | 1050 | 1.8 | 0-50 | 37.5 | 7 |
| iron ore | 5000 | 4500 | 2.2 | 0-50 | 45 | 11 |
| Fixed Double Tripper Car Cantilever Bucket Wheel Stacker-Reclaimer | ||||||
| Conveying Material | Stacking Ability(t/h) | Feeding Ability(t/h) | Material Proportion(t/m3) | Material Granularity(mm) | Turning Radius(m) | Rail Gauge(m) |
| ore | 1500 | 1500 | 2.2 | 0-100 | 45 | 9 |
| bauxite | 2000 | 2000 | 1.3 | 80-150 | 40 | 8 |
| Flexible Single Tripper Car Cantilever Bucket Wheel Stacker-Reclaimer | ||||||
| Conveying Material | Stacking Ability(t/h) | Feeding Ability(t/h) | Material Proportion(t/m3) | Material Granularity(mm) | Turning Radius(m) | Rail Gauge(m) |
| coal | 600 | 250 | 0.85-1 | 0-300 | 25 | 5 |
| coal | 600 | 300 | 0.8-0.95 | 0-50 | 25 | 5 |
| coal | 400 | 400 | 0.8 | 0-50 | 25 | 5 |
| coal | 400 | 400 | 0.8 | 0-50 | 30 | 6 |
| coal | 1200 | 100 | 0.8 | 0-50 | 30 | 6 |
| coal | 1200 | 300 | 0.65-0.78 | 0-50 | 35 | 7 |
| coal | 1250 | 750 | 0.8-0.9 | 0-80 | 35 | 7 |
| coal | 1750 | 1000 | 0.85-0.95 | 0-60 | 33 | 7 |
| coal | 1250 | 800 | 0.85-1 | 0-50 | 335 | 7 |
| coal | 1250 | 1000 | 1 | 0-150 | 40 | 7 |
| coal | 1200 | 1200 | 0.8-0.95 | 0-150 | 40 | 7 |
| Flexible Double Tripper Car Cantilever Bucket Wheel Stacker-Reclaimer | ||||||
| Conveying Material | Stacking Ability(t/h) | Feeding Ability(t/h) | Material Proportion(t/m3) | Material Granularity (mm) | Turning Radius (m) | Rail Gauge(m) |
| coal | 2000 | 650 | 0.8-0.95 | 0-200 | 38 | 8 |
| iron ore | 5000 | 4500 | 2.2 | 0-200 | 46 | 9 |
| iron ore | 1200 | 1200 | 2.2 | 0-200 | 35 | 7 |
| iron ore | 5000 | 4500 | 2.2 | 0-200 | 46 | 9 |
