ASTM A890 4A Ball Valve, API 6D, 4 * 3 IN, CL1500, Hard Seal

Product Name: Metal Seal Ball Valve, Reduced Bore
Design Standard: API 6D
Body Material: ASTM A890 4A
Size: 4 * 3 Inch, DN100*DN75
Pressure: Class 1500 LB, PN250
End Connection: RTJ
Operation: Gearbox

The ball and seat of the metal-seated ball valve utilize a fully metal-to-metal sealing design. Depending on service conditions and user requirements, various advanced hardening technologies can be applied to the ball and seat, including HVOF coating, nickel-based alloy spray welding, high-nickel alloy spray welding, nickel-based tungsten carbide alloy spray welding, and cobalt-based hard alloy spray welding. The sealing face material typically withstands temperatures from 540°C to 600°C, with a maximum resistance of 980°C. It also exhibits excellent wear and impact resistance.
The seat is made of stainless steel with Stellite alloy overlay welding, while the ball is also stainless steel, featuring one of three surface treatment techniques: hard chrome plating, vacuum coating, or tungsten-titanium alloy and Stellite alloy overlay welding—all designed to meet high-temperature and wear resistance requirements. KOSEN's innovative ball manufacturing process achieves high accuracy and a super mirror surface finish.
Additionally, the spring-preloaded seat ensures absolute sealing reliability, stable operating torque, and enhanced safety. Its structural design provides exceptional sealing performance, operational flexibility, and long-term durability.

Technical Specification

» Size Range: NPS 2-36 Inch (DN50–DN900)
» Design Pressure: Class 150–900 LB (PN10–PN160)
» Material: ASTM A105N, A350 LF2, A182 F304, F304L, F316, F316L, F51, etc.
» End Connections: RF, RTJ, BW
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other Specials
» Operation: Handle, worm gear, electric, pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A
» Temperature Range: -29°C to 300°C
» Medium: Water, gas, oil, etc.

Product Features

» Advanced ball and seat hardening technology for enhanced durability.
» Smooth and flexible valve opening and closing operation.
» Fireproof structure design for increased safety.
» Double block and bleed (metal-seated trunnion ball valve) functionality.
» Reliable sealing performance under various operating conditions.
» Blow-out proof stem for added security.
» Corrosion resistance and sulfide stress resistance for harsh environments.
» Optional locking device or stem extension for operational flexibility.
» Optional direct mounting to ISO 5211 for easy actuator installation.
» Full port or reduced bore configurations available.
