ASTM A182 F51 Trunnion Ball Valve, API 6D, 6 * 4 Inch, CL150

The Reduced Bore Ball Valve Plant in China manufactures high-performance valves built to API 6D standards with a robust trunnion-mounted design. Crafted from corrosion-resistant ASTM A182 F51 duplex stainless steel, each valve features a 6 × 4 inch (DN150 × DN100) reduced bore configuration, Class 150 LB / PN20 pressure rating, and RF flanged ends, making it ideal for demanding flow control applications in oil, gas, and petrochemical industries.

Product Name: ASTM A182 F51 Trunnion Ball Valve, Reduced Bore
Type: Trunnion Mounted Ball Valve
Design Standard: API 6D
Body Material: ASTM A182 F51
Size: 6 * 4 Inch, DN150*DN100
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Gear Box
Medium: Water, Oil, Gas, etc
Temperature Range: -46°C to 120°C

Trunnion Mounted Ball Valves allow easy and smooth operation under high line pressure. Carefully aligned bearings ensure low-torque performance. The ball is fixed in position but free to rotate, allowing efficient flow control. All casted trunnion ball valves feature high-quality castings and a fire-safe design, certified according to BS 6755, API 607, and API 6FA. These valves comply with all applicable ASME standards.
Cast steel trunnion ball valves are available in two-piece split body and three-piece bolted body types. They are designed and manufactured in accordance with the latest international standards, including API 6D, ASME B16.34, and BS 5351 or their equivalents. Standard features include fire safety, anti-static construction, and a blow-out-proof stem.

Technical Specification

» Size Ranges: NPS 2-48 Inch (DN50-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Special Alloys
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special alloys
» Seat Materials: RPTFE, DEVLON, PEEK
» End Connections: Flanged RF, RTJ, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design & Manufacture: API 6D, BS 5351, ASME B16.34
» Face-to-Face (End-to-End): ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Test & Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A

Product Features

» Double Block and Bleed (DBB)
» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structure Design
» Anti-static Structure
» Reliable Seat Sealing Structure
» Single Sealing (Automatic Pressure Relief in the Middle Cavity of the Valve)
» Double Sealing (Double Piston Effect)
» Safety Relief Device
» Special Structure for Automatic Pressure Relief Towards Upstream
» Blow-out Proof Stem
» Corrosion Resistance and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Full Port or Reduced Bore Options
