2PC Trunnion Ball Valve, API 6D, ASTM A216 WCB, 12 IN, CL150

Name: 2PC Trunnion Ball Valve, API 6D, ASTM A216 WCB, 12 IN, CL150
SKU: KV-20241225-TMBV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

This Trunnion Mounted Ball Valve, manufactured in China, features a two-piece body design and complies with API 6D standards. Made from ASTM A216 WCB material, it is 12 inches (DN300) in size with a Class 150 LB pressure rating and PN20. The valve is equipped with RF flanged ends and is worm gear operated, ensuring smooth and reliable operation for various industrial applications.

Request a quote

Detail Information

Product Name: Trunnion Mounted Ball Valve, Two Piece Body
Design Standard: API 6D
Body Material: ASTM A216 WCB
Size: 12 Inch, DN300
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Worm Gear

KOSEN Trunnion Mounted Ball Valves offer easy and smooth operation under high line pressure. Carefully aligned bearings facilitate low-torque operation. The ball is fixed in position but free to turn. All cast trunnion ball valves manufactured by us feature reliable, high-quality castings and a fire-safe design, certified according to BS 6755, API 607, and API 6FA. They meet all applicable ASME standards.

Our Cast Steel Trunnion Ball Valves are available in two types: Two-Piece Split Body and Three-Piece Bolted Body. They are designed and manufactured to the latest international standards, including API 6D, ASME B16.34, and BS 5351, or their equivalents. Standard features include fire safety, anti-static protection, and stem blow-out proof design.

Technical Specification

» Size Range: NPS 2-48 Inch (DN50-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Temperature Range: -46°C to 120°C
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Other Special Alloys
» Trim Materials: 13% Cr, SS 304, SS 304L, SS 316, SS 316L, and other special alloys
» Seat Materials: RPTFE, DEVLON, PEEK
» End Connections: Flanged (RF, RTJ), Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture Standards: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connections: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded Ends: ASME B16.25
» Fire Safety Standards: API 607, API 6A

Product Features

» Double Block And Bleed (DBB)
» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structure Design
» Anti-static Structure
» Reliable seat sealing structure
» Single Sealing (Automatic Pressure Relief In Middle Cavity of Valve)
» Double Sealing (Double Piston)
» Safety Relief Device
» Special Structure of Automatic Pressure Relief Towards Upper Stream
» Blow-out Proof Stem
» Corrosion Resistance and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Full Port or Reduce Bore
