ASTM A182 F304 Ball Valve, ASME B16.34, DN25, PN420, 3PC, BW

Product Name: ASTM A182 F304 Ball Valve, Three Pieces
Design Standard: ASME B16.34
Body Material: ASTM A182 F304
Size: DN25, 1 Inch
Pressure: PN420, Class 2500 LB
End Connection: BW End
Operation: Lever

Forged Steel Ball Valves are available in Two-Piece Split Body and Three-Piece Bolted Body configurations. The forged material used in these valves ensures exceptional rigidity and strength, even under maximum rated operating pressure, eliminating the inherent flaws found in cast valves. The design features sufficient wall thickness in the separate body, complemented by high-strength tie bolts, which facilitate easy valve maintenance and provide the necessary support to withstand pipe stress.
The internal components of the valve are meticulously designed and selected, ensuring reliable performance across a wide range of working conditions. These valves are ideal for applications where durability and consistent operation are essential.

Technical Specification

» Size Range: 1/2-2 Inch (DN15-DN50) (for Forged Items)
» Design Pressure: Class 150-1500 LB (PN10-PN250)
» Materials:
   Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, etc
   ASTM A105N, A350 LF2, A182 F11, F22, F304, F304L, F316, F316L
» Trim Materials: 13%Cr, ASTM A182 F11, F22, SS 304, SS 304L, SS 316, SS 316L, and other specials
» Seat Materials: PTFE, RPTFE, PEEK
» Ends Connections: SW, FNPT, BW
» Design and Manufacture: ASME B16.34
» Face to Face (End to End): ANSI B16.10
» Flanged Connection: ANSI B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded Ends: ANSI B16.5
» Threaded Ends: ASME B1.20.1
» Socket-Weld Ends: ASME B16.11
» Medium: Water, Gas, Oil, etc.
» Temperature Range: -29°C to 150°C

Product Features

» Forged Steel Floating Ball Valves are offered in One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body configurations. These valves are designed and manufactured according to the latest international standards, including API 6D, ASME B16.34, BS 5351, and their equivalents. Key features of these valves include:
» Fire Safe: Engineered to operate safely under fire conditions.
» Anti-Static: Designed to prevent static discharge, enhancing safety.
» Blow-out Proof: Ensures the integrity of the valve stem, preventing blow-out under pressure.
» These features make Forged Steel Floating Ball Valves highly reliable and suitable for critical applications in various industries.
