API 602 Globe Valve, ASTM A105N, 3 Inch, 1500 LB, BB, BW

This Forged Steel Globe Valve, manufactured to API 602 standards, is crafted from ASTM A105N forged steel, ensuring robustness and durability. With a 3-inch size and a high-pressure rating of Class 1500 LB (PN250), it is designed for demanding industrial applications where reliable performance under high pressures is essential. The valve features a bolted bonnet for secure sealing, a reduced bore design for efficient flow control, and butt weld ends for strong and welded connections in pipelines. Equipped with an STL (Stellite) metal seat, it provides excellent resistance to wear and corrosion, ensuring longevity and dependable operation in critical environments.

API 602 Forged Globe Valve

Valve description: Bolted bonnet, Reduced bore, BW, renewable seat
Design & Manufacture: API 602
Body material: ASTM A105N
Nominal diameter: 3 Inch, DN80
Nominal class: Class 1500 LB, PN250
End connection: Butt-Welded (BW)
Metal seat: STL
Face to face: MFR, API 602
Mode of operation: Handwheel
Test and inspection: API 598

We are Bolted Bonnet Forged globe Valve manufacturer

Design Features


• Forged steel construction with outside screw and yoke, rising stem design.
• Non-rising handwheel with integral backseat.
• Available in reduced bore or full port configurations.
• Connection types include socket welded, threaded, butt welded, and flanged ends.
• Compatible with SW (Socket Weld), NPT (National Pipe Thread), RF (Raised Face), or BW (Butt Weld) connections.
• Options for welded bonnet, pressure-sealed bonnet, and bolted bonnet.
• Features a solid wedge, renewable seat rings, and spiral wound gasket.

DESIGN STANDARDS

Design / Manufacture: API 602, ASME B16.34
Face to Face Length (Dimension): ASME B16.10, EN 558-1 Gr.14 (DIN 3202-F4), DIN 3202-F5, DIN 3202-F7, BS 5163
Testing: API 598, API 6D, EN 12266-1, EN 1074-1, ISO 5208
Flanged Dimension: ASME B16.5, EN 1092-1, BS 4504, DIN 2501
Butt welding Ends: ASME B16.25, DIN 3239
Socket Welded Ends: ASME B16.11
Threaded Ends: ASME B1.20.1
Hub ends on request.

Products Range

Size Range: 1/2 Inch - 3 Inch (DN15-DN80)
Pressure Range: ANSI Class 150 LB-4500 LB
Body Materials: ASTM A105, ASTM A350 LF2, ASTM A182 F9, F11, F22, F304, F304L, F316, F316L, F321, F51, Alloy Steel, etc.
