40kW 50kVA Diesel Generator, 50Hz, YTO, Brushless Alternator

Name: China Manufacturers
Address: Room 2607, Meixin Plaza, No. 879 Xiahe Road, Siming District, Xiamen, CHINA
Telephone: 13276021100
Price range: $$$

Mar 12, 2024

Product Name: 40kW 50kVA Diesel Generator
Model: GGS-50-Y
Engine Brand: YTO
Frequency: 50Hz
Prime Power: 40kW, 50kVA
Rated Voltage: 230/400V
Cooling Method: Water Cooled
Engine Type: 4 Cylinder, 4 Stroke
Alternator Type: Brushless, Self-Excited, 3 Phase & 4 Wire
Dimension (L x W x H): 2400 x 950 x 1350 mm

Technical Data

Generator Specification
Generator Model	GGS-50-Y
Frequency	50Hz
Prime Power	40kW/50kVA
Standby Power	44kW/55kVA
Rated Voltage	400V, 230V
Rated Current	79A
Dimension (L x W x H) (mm)	2400 x 950 x 1350
Net Weight (KG)	1150
Engine Specification
Engine Brand	YTO
Model	LR4B5-D
Cooling System	Water Cooled
Aspiration	Natural Aspiration
Fuel System	Direct Inject
Number of Cylinders	4 Cylinder In Line
Cycle	4 Stroke
Starting Method	Electric Start
Displacement	4.95 L
Bore x Stroke	105 x 135 mm
Compression Ratio	17.0:1
Rated Speed	1500rpm
Rated Power (With Fan)	48kW
Governor Type	Mechanical
Alternator Specification
Alternator Brand	Stamford UCI224D
Exciter Type	Brushless, Self-Excitation
Phase	3
Wiring Type	3 Phase 4 Wire, Y Type
Power Factor	0.8
Protection Grade	IP23
Insulation Grade	Class H
