720kW 900kVA Diesel Genset, Cummins KTA38-G2A, 50 Hz, 1299 A

Mar 21, 2025

Product Name: 720kW Cummins Diesel Generator Set for Sale
Fuel Type: Diesel
Engine: Cummins KTA38-G2A
Alternator: Stamford LVI634D
Control Panel: Deepsea DSE7320
Rated Power: 720kW, 900kVA
Max Power: 800kW, 1000kVA
Frequency: 50 Hz
Rated Voltage: 400/230 V
Rated Current: 1299.1 A
Fuel Tank Capacity: 900 L
Dimensions (Open-type): 4243 * 1820 * 2500 mm
Weight (Open-type): 7650 kg
Noise Level (Soundproof): 80 dBA
Battery: Four 150 Amps Free Maintenance Batteries

Cummins Diesel Engine – KTA38-G2A

Engine Brand	Cummins
Engine Model	KTA38-G2A
Number of Cylinders	12 Cylinder V-Type
Aspiration	Turbocharged & Aftercooled
Governor	Electric
Max. Output Power	895 kW
Displacement	37.8 L
Compression Ratio	14.5 : 1
Starting Voltage	24 V
Bore	159 mm
Stroke	159 mm
Lubrication Oil Capacity	135 L
Intake Air Flow	68 m³/min
Fuel Consumption (100% Load)	191 L/h

Stamford Alternator – LVI634D

Brand	Stamford
Model	LVI634D
Rated Output	910kVA
Frequency	50 Hz
Altitude	≤1000 m
Insulation	Class H
Phase	3 Phase
Working Temperature (No Power Decrease)	≤40°C
Working Altitude (No Power Decrease)	≤1000 m
Automatic Voltage Regulation	MX321
Protection Grade	IP23
Optional Alternators	Leroy Somer, Marathon, Mecc Alte

Control Panel – Deepsea DSE7320

Controller Brand	Deepsea
Controller Model	DSE7320 MKII
Breaker Brand	Delixi
Breaker Capacity	ACB 1600A
Battery Charger	Smartgen Model BAC06A
Emergency Stop Button	Yes
Automatic Mains Fail (AMF)	Yes
Fuel Level Monitoring	Yes
Automatic Transfer Switch (ATS)	Optional
Protection Features	High Water Temp, Low Oil Pressure, Over/Under Speed, Over/Under Voltage, Over/Under Frequency, Loss of Excitation, Overload, Charging Alternator Fails, and more.
Optional Controllers	Deepsea, Smartgen, ComAp
