620kW Diesel Generator Set, 60Hz, Cummins KT38-G, Soundproof

Mar 24, 2025

Product Name: 620kW 775kVA Cummins Silent Diesel Generator Set, Soundproof Canopy
Fuel Type: Diesel
Engine: Cummins KT38-G
Alternator: Stamford HCI544F
Frequency: 60 Hz
Prime Power: 620kW, 775kVA
Standby Power: 682kW, 853kVA
Output Voltage: 240 V
Rated Current: 1134 A
Oil Consumption: 0.5 L/H
Noise Level: 70 dBA At 7M

Engine Specifications

Engine Brand	Cummins
Engine Model	KT38-G
No. of Cylinders	12-Cylinder V-Type
Bore × Stroke	159 mm × 159 mm
Displacement	37.8 L
Cooling Fan Air Flow	1825 m³/min
Compressed Air Flow	55.2 m³/min
Exhaust Gas Flow	158.6 m³/min
Exhaust Gas Temperature	552°C
Lubrication Oil Capacity	135 L
Cooling Water Capacity	194 L
Starting Voltage	24 V
Max. Engine Output Power	747 kW

Alternator Specifications

Alternator Brand	Stamford
Alternator Model	HCI544F
Rated Output	775kVA
Frequency	60 Hz
Altitude	≤1000 m
Insulation Class	H
Protection Grade	IP23
Optional Alternators	Leroy Somer, Marathon, Mecc Alte, Chinese Brushless Alternator

Control Panel Specifications

Controller Brand	Deepsea
Controller Model	DSE7320
Key Functions	Automatic genset start/stop, Automatic battery charger, Emergency stop, AMF (Automatic Mains Fault), Remote control, Microprocessor-based design, LED alarm indication and Sound alarm
Controller Display	Generator voltage (Uab, Ubc, Uca), Generator current (Ua, Ub, Uc), Generator temperature (°C/°F), Generator frequency (Hz), Generator power (kW, kVA, kWh, kVAr, kVArh, kVAh), Generator starts count (max 999999 times), Generator pressure (kPa/Psi/Bar), Charging voltage, Battery voltage (V DC)
Protection Features	Over/Under Speed Alarm and Shutdown, Start/Stop Failure Alarm, Over Current Alarm and Shutdown, Under/Over Generator Voltage Alarm and Shutdown, Low Oil Pressure Alarm and Shutdown, High Engine Temperature Alarm and Shutdown, Over Load Alarm and Shutdown, Low/High Battery Voltage Alarm, Loss of Speed Signal Alarm and Shutdown, Charge Fail Alarm
