Spherical Fully Welded Ball Valve, ASTM A105, 28 Inch, CL300

Product Name: Spherical Body Fully Welded Ball Valve
Design Standard: ASME B16.34
Body Material: ASTM A105
Size: 28 Inch, DN700
Pressure: PN40, Class 300 LB
End Connection: Butt Welded

Fully Welded Ball Valves, also known as Welded Body Ball Valves, are designed for use in a variety of critical applications, including water and gas-supply systems, heat-power engineering, housing and communal services, and process lines in industries like chemical, oil-refining, and pulp-and-paper production.
The valves are fabricated with a fully welded body for enhanced strength and durability. The forging materials undergo ultrasonic testing in compliance with ASME nondestructive flaw detection standards, while the welding slope on the connection face is checked with liquid penetration testing. A corrosion allowance is included in the body wall thickness to ensure long-term reliability.
The valve components, including the carbon steel stem, fixed shaft, ball, seat, and seat ring, are chemically nickel-plated per ASTM B733 and B656 to enhance corrosion resistance. Additionally, various corrosion-resistant materials are available based on user needs. For environments with sulfurization, materials can be selected in accordance with NACE MR 0175/ISO 15156 or NACE MR 0103 standards, with strict quality control processes to ensure compliance with all service conditions.
These valves provide robust sealing and reliable performance even in harsh environments, making them ideal for applications requiring long-term service and minimal maintenance.


Technical Specifications

» Size Range: NPS 1/2-48 Inch (DN15-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: Forged Carbon Steel, Forged Stainless Steel
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» Seat Materials: RPTFE, DEVLON, PEEK
» Ends Connections: Flanged RF, RTJ, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A
» Temperature Range: -46°C to 120°C
» Medium: Water, Gas, Oil, etc.

Product Features

» Fully Welded Body
» Three-Piece or Two-Piece Body
» Metal-to-Metal Sealing or Soft Sealing
» Full Bore or Reduced Bore
» Flange End or Welding End
» Double Block and Bleed
» Locking Device
» Single Piston Effect / Double Piston Effect
» Automatic Internal Relief of Body Pressure
» Emergency Sealant Injection System
» Fire-Safe Design, Anti-static Device
» Anti-Blowout Stem Design
» Body Vent Device
» Suitable for Underground Use
» Optional Extended Bonnet
» Optional Extended Stem
» Ensures No Potential Body Joint Leaks for Environmental Concern
» Forged Steel Body for Uniform Fine Grain Structure and Toughness, Free from Common Casting Defects (such as Porosity and Gas Holes)
