Metal Seated Swing Check Valve, API 6D, CF8M, 12 IN, CL1500

Product Name: Metallic Seated Swing Check Valve
Design Standard: API 6D
Body Material: ASTM A351 CF8M
Size: NPS 12 Inch, DN300
Pressure: Class 1500 LB, PN250
End Connection: RTJ Flanged

Universal Cast Steel Check Valves are designed and manufactured to strict international standards, including API 6D, BS 1868, and ASME B16.34, ensuring low flow resistance and minimal pressure drop. These valves are suitable for installation in horizontal pipelines only. The valve's seat ring is lapped and screwed for tight shutoff and long service life. The disc is meticulously designed and guided for efficient automatic closure at zero pressure, offering a compact structure and low-emission service. In its standard configuration, the swing check valve features a bolted cover and a free-swinging clapper, which responds to flow conditions to close the valve. While best suited for horizontal installations, for heavier disc weights or to prevent chattering, dampers or counterweights may be added.

Technical Specifications

» Nominal Diameter: NPS 2–24 Inch (DN50–DN600)
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3, CF3M, CF8C
» End Connections: Flanged (FF, RF, RTJ) to international standards
» Design and Manufacture Standards: BS 1868, API 6D, DIN 3352
» Face-to-Face (End-to-End): ANSI B16.10, EN 558 Series
» Flanged Connections: ASME B16.5, ASME B16.47, EN 1092 Series
» Butt Welded End: ANSI B16.25
» Test and Inspection Standards: API 598, ISO 5208, EN 12266-1
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, etc.

Product Features

» Backflow Prevention: Cast steel swing check valves are designed to prevent backflow in the pipeline. The media flows through the valve in a straight line, ensuring minimal pressure drop.
» Self-Operated Disc: The disc swings into the open position when the media flows through the line, and back pressure holds the disc in the closed position.
» Flexible Installation: These valves can be installed in both horizontal and vertical lines, provided they are oriented according to the media flow direction, as indicated by the flow direction arrow on the body.
» Customizable Accessories: A range of accessories, including bypasses, locking devices, counterweights, and more, are available to meet specific customer requirements.
