HC276 Floating Ball Valve, Hastelloy C276, DN50, PN160, 2 IN

Name: HC276 Floating Ball Valve, Hastelloy C276, DN50, PN160, 2 IN
SKU: KV-20250226-FBV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The HC276 Floating Ball Valve Supplier offers high-performance ball valves designed to meet API 6D standards. These valves feature a robust Hastelloy C276 body, providing exceptional corrosion resistance and durability. Available in DN50 (2 inches) size, they operate at a pressure rating of PN160 and are classified at 900 LB. The valves come with flanged ends for secure connections and feature a bare stem design.

Request a quote

Detail Information

Product Name: HC276 Forged Floating Ball Valve
Design Standard: API 6D
Body Material: HC276 (Equivalent to Hastelloy C276)
Size: DN50, 2 Inch
Pressure: PN160, Class 900 LB
End Connection: Flanged
Operation: Bare Stem

The Forged Floating Ball Valve design supports the ball with two PTFE seats—one on the upstream side and the other on the downstream side of the ball. The upstream pressure pushes the ball, compressing the downstream seat to achieve a complete fluid shutoff. All Floating Ball Valves are crafted from high-quality castings with a fire-safe design, certified according to BS 6755, API 607, and API 6FA, and meet applicable ASME standards. Available in One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body configurations, Floating Ball Valves are designed and manufactured in compliance with the latest international standards, including API 6D, ASME B16.34, and BS 5351 or their equivalents. Standard features include fire-safe, anti-static, and blow-out prevention for added reliability and safety.

Technical Specifications

» Size Range: NPS 1/2-10 Inch (DN15-DN250)
» Design Pressure: Class 150-1500 LB (PN10-PN250)
» Materials: Forged Carbon Steel, Stainless Steel, Duplex Steel, or other special materials (ASTM A105N, A350 LF2, A182 F11, F22, F304, F304L, F316, F316L)
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» Seat Materials: Nylon, RPTFE, PEEK
» End Connections: RF and RTJ flange, welded
» Operation: Handle, worm gear, electric, pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face-to-Face (End-to-End): ASME B16.10
» Flanged Connection: ASME B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A
» Temperature Range: -46°C to 120°C

Product Features

» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structure Design
» Anti-static Structure
» Reliable Seat Sealing Structure
» Special Structure for Automatic Pressure Relief Towards Upstream
» Blow-out Proof Stem & Stem Flyout Prevention Design
» Corrosion Resistance & Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Full Port or Reduced Bore Options
