GS-C25 Angle Globe Valve, DIN 3356, DN50, PN16, Bellows Seal

Product Name: Angle Type Bellows Sealed Globe Valve
Design Standard: DIN 3356
Body Material: Carbon Steel GS-C25
Size: DN50, 2 Inch
Pressure: PN16, Class 150 LB
End Connection: RF Flanged
Operation: Handwheel

The Bellows Sealed Globe Valve incorporates advanced foreign technology, featuring a double bellows design welded to the valve stem to maintain stable operating performance and prevent valve vibration caused by plug movement. At high temperatures, the stem does not contact the medium, ensuring zero leakage. The design guarantees sufficient strength and toughness, enabling the valve to endure tens of thousands of operating cycles.
The ergonomically designed handwheel offers a longer service life while ensuring ease of operation. The bellows cut-off valve operates with a plug-shaped valve, with either a flat or conical sealing face. The valve moves straight along the fluid’s center line, making it one of the most widely used types. It is favored for its minimal friction between sealing surfaces during operation, ensuring durability, a compact opening height, ease of manufacturing, and simplified dimensioning.

Technical Specifications

» Nominal Diameter: DN15–DN400 (1/2–16 Inch)
» Design Pressure: PN16–PN64 (Class 150–600 LB)
» Materials:
   Body: 1.0619, GS-C25, ASTM A216 WCB, WCC, A352 LCB, LCC, A351 CF8, CF8M, CF3, CF3M
   Bellows: SS 304, SS 316, SS 316L, etc
» End Connection: Flanged, Welded, or Threaded Ends
» Operation: Handwheel, Bevel Gear, Electric, Pneumatic
» Design and Manufacture: DIN 3356
» Inspection and Testing: ISO 5208, EN 12266
» Flanged Ends Dimension: DIN 2543, DIN 2544, DIN 2545
» Butt-Welded Ends Dimension: EN 12627
» Face-to-Face and End-to-End: DIN 3202, EN 558-1, ISO 5752
» Pressure-Temperature Ratings: DIN 2401
» Test & Inspection: DIN 3230
» Medium: Water, Gas, Oil, etc.
» Temperature Range: -29°C to 595°C

Product Features

» Reliable Design: Bellows Sealed Globe Valves are known for their reasonable structure, reliable sealing, excellent performance, and aesthetic appearance.
» Wide Material Options: Available with various cast body and trim materials, offering the most economical solution for your process and steam system.
» Durable Sealing Surface: The sealing surface is hard-faced with Cr. Alloy for enhanced resistance to abrasion, corrosion, and friction, ensuring a longer service life. Double sealing guarantees tight shut-off and optimal operation.
» Stem Construction: The stem is quenched and tempered with nitriding treatment, providing excellent anti-corrosion and anti-friction properties.
» Optional Stem Position Indicator: Available to provide a direct visual indication of the valve’s on/off status.
