Electric Operated Diaphragm Pump, Polypropylene, DN10-DN125

Product Name: Electric Operated Diaphragm Pump
Port Sizes: 10-125 mm, DN10-DN125
Pump Material: Polypropylene (PP, PVDF, PTFE)
Diaphragm: VITON, PTFE, EPDM, NBR
Ball: PTFE, Stainless Steel, VITON, Ceramic
Seat: PTFE, Stainless Steel, VITON
Maximum Particle Diameter: 6 mm
Connection: Threaded End
Temperature: -20°C to 150°C
Medium: Various Chemicals: Acids, Alkalis, Solvents, etc.

Electric Diaphragm Pump Description

The DBY Electric Diaphragm Pump is a modern, advanced pump that has gained widespread adoption in recent years due to breakthroughs in diaphragm material technology. It is increasingly used in industrialized nations as a replacement for centrifugal pumps and screw pumps. This pump is suitable for low-pressure applications, with an outlet pressure ≤ 3 kgf/cm². Designed based on the U.S. company ABEL's prototype, it is used in a wide range of industries, including petrochemical, ceramics, metallurgy, and more.

Electric Diaphragm Pump Features

» Self-Priming Capability: No irrigation water required, with a self-absorption capacity up to 3 meters.

» Particle Handling: Capable of effortlessly handling particles up to 10 mm in diameter, such as mud and other similar materials.

» Leak-Free Operation: The diaphragm separates the media from the transmission machinery, preventing leakage. This sealless design significantly extends the service life of the pump. The diaphragm material can be customized to meet different requirements, with options such as neoprene, Viton, NBR, PTFE, and Teflon (F46).

» Durable Flow Parts: The pump's flow components are available in various materials, including cast iron, stainless steel, rubber lining, and aluminum. The motor options include standard motors, explosion-proof motors, geared motors, and electromagnetic speed motors.

Electric Diaphragm Pump Usage

» Toxic, Flammable, and Volatile Liquids: Suitable for transporting various hazardous liquids.

» Corrosive Liquids: Handles acids, alkalis, and other strong corrosive liquids.

» High-Temperature Media: Capable of transporting media at temperatures up to 150°C.

» Pre-Filter Applications: Ideal for use as a pre-filter in various pressure devices.

» Hot Water Recovery: Used for hot water recovery and recycling.

» Oil Transfer: Suitable for tankers, oil depots, and oil loading and unloading applications.

» Food Processing: Can pump materials like pickle jam, mashed potatoes, chocolate, and other food products.

» Paint and Rubber Handling: Suitable for pumping paint, rubber, pigment binder, and similar substances.

» Construction and Industrial Materials: Can transport various materials like porcelain glaze, cement, grout, mortar, mud, latex emulsions, organic solvents, and fillers.

» Tanker and Barge Cleaning: Ideal for use in clearing water and residual oil from tankers and barges.

» Yeast and Syrup: Pumps yeast slurry, hops, syrup, molasses, and similar products.

» Mining and Sewage: Effective for pumping sediment from mines, tunnels, sewers, and sewage systems.

» Specialized Suction: Suitable for a wide variety of special suction mediums.
