Electric Actuated Knife Gate Valves, GGG40, DN300, PN10, Lug

The Electric Actuated Knife Gate Valve is with a ductile iron GGG40 body. This unidirectional valve features a 12-inch (DN300) size, a PN10 pressure rating (Class 150 LB), and lug ends for easy installation and maintenance. Its electric actuator ensures precise and reliable operation, making it ideal for systems where automation and robust performance are essential. The valve is particularly suitable for handling abrasive or viscous fluids in both on-off and throttling applications.

Product Name: Electric Actuated Knife Gate Valves
Type: Unidirectional Knife Gate Valve
Body Material: Ductile Iron GGG40
Size: DN300, 12 Inch
Pressure: PN10, Class 150 LB
End Connection: Lug
Operation: Electric Actuator

The Knife Gate Valve is a unidirectional wafer valve designed for on-off operation in industrial pipelines. Its unique structure prevents clogging during shutoff when handling flow with particles. The beveled knife gate design enhances shear stress, ensuring smooth flow penetration.

Technical Specification

» Structure: Bonneted Knife Gate Valve
» Nominal Diameter: NPS 2-24 Inch (DN50-DN600)
» Design Pressure: PN10, PN16, Class 150 LB
» Max Working Pressure:
   DN50 to DN250: 10 bar
   DN300 to DN450: 7 bar
   DN500 to DN600: 4 bar
» Body Material: Ductile Iron, Carbon Steel, Stainless Steel, Special Alloys, etc.
» Disc Material: Stainless Steel Chrome Plated, Special Alloys, etc.
» Seat Material: Stainless Steel + STL, EPDM (120°C), Viton (200°C), PTFE (200°C), NBR (80°C)
» Flange Standard: GB/T 9113.1, JB/T 79.1, HG 20592, ASME B16.5, EN 1092-1
» Face to Face: MSS SP-81
» Applications: Pulp & Paper, Water Treatment, Beverage & Food, Fine Chemicals, Power Plants, Steel Industry, etc.
» Temperature Range: -29°C to +538°C

Product Features

» Cast-in guide claws at the port bottom secure the gate, preventing shutoff clogging while ensuring a tight seal.
» Integral body design allows easy assembly with zero shell leakage.
» Full port design minimizes pressure drop and maximizes flow capacity.
» PTFE resilient points prevent metal-to-metal contact between the gate and body.
» Ultra-thin body and compact construction enable easy installation.
» Beveled knife edge enhances cutting stress and sealing performance.
» Optional increased gate thickness for higher pressure applications.
» Replaceable side-entry seat lowers maintenance costs.
» L-shape seat retainer locks the seat and protects it from direct flow flushing.
» Optional stem cover extends stem service life.
» Two thrust bearings reduce operating torque.
» Grease nipple available for easy bearing lubrication.
