Duplex Steel Butterfly Valve, API 609, A890 5A, 8 IN, CL150

Product Name: High Performance Butterfly Valve
Design Standard: API 609 Category B
Body Material: ASTM A890 5A
Size: 8 Inch, DN200
Pressure: Class 150 LB, PN20
End Connection: Lug
Operation: Wormgear

The Fire-Safe High-Performance Butterfly Valve is designed with dual seats to ensure optimal sealing and reliability. The primary seat is constructed from RPTFE (Reinforced Poly Tetrafluoroethylene), providing excellent sealing performance for tight shut-off and preventing leakage. This soft seat material enhances the valve's overall functionality by offering superior sealing properties. In addition, the valve features a fire-safe metal seat, providing enhanced resistance to high temperatures and ensuring reliable operation during fire incidents. The combination of the RPTFE soft seat and the fire-safe metal seat ensures consistent performance in both normal and emergency conditions, making this valve an ideal solution for applications where safety, efficiency, and reliability are critical.

Technical Specification

» Design: Bi-Eccentric
» Normal Size Range:
   Class 150 LB: 2-60 Inch
   Class 300 LB: 2-48 Inch
   Class 600 LB: 2-24 Inch
» Normal Pressure Rating: Class 150-600 LB, PN10–PN40, 10K–20K
» Standard: API 609 Category B
» Body: ASTM A351 CF8, CF8M, CF3, CF3M, A890 4A, 5A, 6A
» Disc: ASTM A351 CF8, CF8M, CF3, CF3M, A890 4A, 5A, 6A
» Seat: 316L + RPTFE
» Shaft: 17-4PH
» Shutoff Rating: Class VI, Bubble Tight
» Operation: Handle, Worm Gear, Pneumatic, Electric
» Temperature Range: Soft Seat: -29°C to 150°C
» Medium: Water, Gas, Oil, etc.

Application Scope

» Chemical and Petrochemical industries
» Liquefied Gas and Refrigeration systems
» Heavy Industrial applications
» Power and Co-Generation Plants
» Steel and Iron Works
» Commercial facilities
» Pulp and Paper Mills
» Oil Refineries and Oil Fields
» Shipbuilding
» Hydrocarbon Processing
» Gas Piping systems
» Local Area Energy Supply
» Industrial construction projects
» Marine applications
