Carbon Steel Trunnion Ball Valves, ASTM A105, DN150, PN100

Product Name: Carbon Steel Trunnion Ball Valves
Type: Trunnion Mounted Ball Valve
Body Material: ASTM A105, Forged Carbon Steel
Size Range: DN150, 150 mm, 6 Inch
Design Pressure: PN100, Class 600 LB
Ends Connections: RF Flanged
Operation: Gear
Medium: Water, Gas, Oil, etc
Temperature Range: -46°C to 120°C

Trunnion-mounted ball valves are designed to provide smooth and reliable operation under high line pressure conditions. Precisely aligned bearings ensure low operating torque, while the trunnion-supported ball remains fixed in position and free to rotate, minimizing seat load and operating effort. All cast steel trunnion ball valves are manufactured using high-quality castings and incorporate a fire-safe design certified in accordance with BS 6755, API 607, and API 6FA. These valves comply with all applicable ASME standards. Cast steel trunnion ball valves are available in two-piece split-body and three-piece bolted-body configurations. They are designed and manufactured to the latest international standards, including API 6D, ASME B16.34, BS 5351, or equivalent specifications. Standard features include fire-safe construction, anti-static design, and a blowout-proof stem.

Technical Specification

» Product: Trunnion Mounted Ball Valve
» Size Ranges: NPS 2–48 Inch (DN50–DN1200)
» Temperature Range: -46°C to 120°C
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Other Specials
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other specials
» Seat Materials: RPTFE, DEVLON, PEEK
» End Connections: Flanged RF, RTJ, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A

Product Features

» Double Block and Bleed (DBB) for enhanced isolation and safety
» Low operating torque for smooth valve operation
» Emergency sealing device for high-reliability under abnormal conditions
» Fireproof structural design to meet fire-safe standards
» Anti-static design to prevent electrostatic discharge
» Reliable seat sealing structure for tight shutoff
» Single sealing with automatic pressure relief in the valve’s middle cavity
» Double sealing (double piston) for added safety
» Safety relief device to prevent overpressure
» Special automatic pressure relief structure toward the upstream side
» Blowout-proof stem with stem flyout prevention design
» Corrosion resistance and sulfide stress cracking resistance
» Optional locking device or stem extension for added safety and accessibility
» Optional direct mounting to ISO 5211
» Full-port or reduced-bore design options
