ASTM A217 WC6 Gate Valve, ASME B16.34, 10 Inch, 900 LB, PSB

Product Name: ASTM A217 WC6 Gate Valve, Pressure Seal Bonnet
Design Standard: ASME B16.34, API 600
Body Material: ASTM A217 WC6
Size: 10 Inch, DN250
Pressure: Class 900 LB, PN150
End Connection: Flanged
Operation: Bevel Gear

Pressure Seal Gate Valves are designed according to API 600 and ASME B16.34 standards for high-temperature and high-pressure service, making them ideal for use in fossil fuel power plants. Compared to bolted bonnet joint valves, pressure seal valves offer superior sealing reliability at the bonnet joint. This design makes the valves more compact, rigid, and cost-effective in terms of maintenance, particularly in demanding high-temperature and high-pressure environments.

Technical Specifications

» Nominal Diameter: 2-24 Inch (DN50-DN600)
» Design Pressure: Class 600-2500 LB (PN100-PN420)
» Materials: Cast or Forged Carbon Steel, Stainless Steel, Duplex Steel, Special Materials, etc.
» Trim Materials: 13%Cr, ASTM A182 F11, F22, SS 304
» End Connections: BW, RF, RTJ
» Operation: Hand wheel, bevel gear, electric, pneumatic
» Design and Manufacture: ASME B16.34, API 600, API 6D, BS 1414
» Face to Face (End to End): ANSI B16.10, API 6D
» Flanged Connection: ANSI B16.5
» Butt Welded End: ANSI B16.25
» Test and Inspection: API 598, API 6D
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, etc.
» Back-Up Ring: Absorbs thrust applied by internal pressure
» Thrust Ring: Protects the soft metallic gasket from deformation
» Gasket: Unique angular design provides superior sealing
» Optional: Bypass system, live loading packing, and O-ring seal available upon request

Product Features

» Versatile Applications – Ideal for steam-generation stations, industrial chemical plants, and thermal power plants, ensuring excellent service across various industries.
» Material Options – Available in Cast Steel and Forged Steel body designs to meet diverse application needs.
» Reliable and Flexible Design – Features a simple structure with the ability to compensate for sealing face angle deviations, improving process performance.
» Durable Sealing – Seat and gate disc sealing surfaces are overlaid with iron-base, Co-base, or carbide alloys for extended durability.
