ASTM A182 F51 Ball Valve, API 6D, 3 IN, 900 LB, Metal Seated

The ASTM A182 F51 Ball Valve, manufactured to API 6D standards, features a 3-inch (DN80) size and is rated for Class 900 LB (PN150) pressure. It is metal-seated for enhanced durability in high-pressure applications and comes with a bare stem design for efficient operation. Equipped with RF flanged ends, this valve ensures secure and leak-proof connections.

Product Name: ASTM A182 F51 Ball Valve, Metal Seated
Design Standard: API 6D
Body Material: ASTM A182 F51
Size: 3 Inch, DN80
Pressure: Class 900 LB, PN150
End Connection: RF Flanged
Operation: Bare Stem

The metal-seated ball valve features a metal-to-metal sealing mechanism between the ball and seat. Advanced hardening technologies, such as HVOF coating, nickel-based alloy spray welding, high-nickel alloy spray welding, tungsten carbide alloy spray welding, and cobalt-based hard alloy spray welding, can be applied based on specific service conditions and user needs. These techniques enable the sealing material to endure temperatures from 540°C to 980°C while delivering exceptional wear and impact resistance.
The seat is crafted from stainless steel with a stellite alloy overlay, while the ball, also stainless steel, undergoes treatments like hard chrome plating, vacuum coating, tungsten-titanium alloy application, or stellite alloy overlay welding. These processes ensure outstanding resistance to heat and wear. KOSEN’s advanced ball manufacturing techniques achieve precise dimensions and an ultra-smooth mirror surface finish.
A key feature of the valve is its spring-preloaded seat, which guarantees dependable sealing and stable torque during operation. The overall design prioritizes safety, sealing reliability, and operational ease.

Technical Specification

» Size Range: NPS 1/2–36 Inch (DN15–DN900)
» Temperature Range: -29°C to 300°C
» Pressure Range: Class 150-900 LB (PN10–PN160)
» Materials:
  Cast Carbon Steel, Stainless Steel, Duplex Steel;
  ASTM A105N, A352 LF2, A182 F304, F304L, F316, F316L, F51, etc.
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and custom Options
» Mediums: Water, Gas, Oil, etc
» End Connections: Flanged (RF, RTJ), Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design Standards: API 6D, BS 5351, ASME B16.34
» Face-to-Face: ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Butt Welded End: ASME B16.25
» Testing and Inspection: API 598, API 6D
» Fire Safety: API 607, API 6A

Product Features

» Advanced Ball and Seat Hardening Technology
» Flexible Valve Opening and Closing
» Fireproof Structure Design
» Double Block and Bleed (Metal-Seated Trunnion Ball Valve)
» Reliable Sealing Performance
» Blow-Out-Proof Stem
» Corrosion Resistance and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Full Port or Reduced Bore
