10000 PSI Needle Valve, SS 316, Customized Sizes, BW Ends

Product Name: Butt Weld Needle Valve
Body Material: Stainless Steel SS 316
Size: Customized
Pressure: 10000 PSI
End Connection: Butt Welding
Operation: Manual

The forged body socket welding needle valve is designed for high-pressure and high-temperature conditions, where the sealing surface experiences extreme wear. To meet these challenges, the valve’s sealing surface is made from cobalt chromium tungsten, ensuring excellent performance and reasonable cost. When the valve is in the open position, the valve seat and valve disc no longer make contact, minimizing mechanical wear. The sealing components (valve seat and valve disc) are easy to repair or replace without removing the entire valve from the pipeline, making it ideal for welded valve and pipeline connections. Additionally, the valve changes the flow direction of the medium as it passes through.

Technical Specifications

» Usage: Cut-off function
» Nominal Diameter: DN6-DN80, 1/8-3 Inch
» Pressure Environment: High Pressure
» Main Material: Stainless Steel SS 316
» Type: Through type (channel position)
» Working Temperature: -40°C to 120°C
» Drive Mode: Manual

Product Features

» Durable Valve Needle: The valve needle is treated with special technology, ensuring high hardness and durability without damage.
» Reliable Sealing: Specially designed compression sealing gasket nuts provide a reliable external seal, preventing leakage.
» Preventing Fluid Entry: The connecting nut between the valve core and valve body is placed behind the sealing gasket, preventing fluid from entering the nut area and maintaining good external sealing.
» Non-Rotating Valve Core: The non-rotating valve core structure ensures no rotational wear between the valve core and body. The core and seat only move up and down, keeping the sealing line in a consistent position, which improves sealing             tightness and extends the valve's lifespan.
