10000 PSI Globe Valve, 4130/F60/F65, 17-4PH Trim, 1-13/16 IN

Name: 10000 PSI Globe Valve, 4130/F60/F65, 17-4PH Trim, 1-13/16 IN
SKU: GLV-183103022
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading 10,000 PSI globe valve provider in China, we supply valves engineered to meet API 6A standards for reliability in critical high-pressure applications. These globe valves feature robust body materials such as AISI 4130 alloy steel or ASTM A694 F60/F65, ensuring exceptional strength and durability under demanding conditions. Trim options in 17-4PH stainless steel or Inconel deliver superior sealing performance and resistance to wear. Designed in 1-13/16 inch size with smooth gear operation, they are equipped with TCC or STL seating to provide long-lasting service in harsh operating environments.

Request a quote

Detail Information

Valve Description:
183103022 API 6A Globe Valve
Design Standard: API 6A
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2,000 PSI-15,000 PSI
Bore Type: Standard
Test and Inspection: API 6A
Operation: Lever/Gear/Bare Shaft
Body Material: AISI 4130/ASTM A694 F60/ASTM A694 F65/Inconel
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Seat Insert: TCC or STL Hardfaced
Face to Face: ASME B16.10/MFG'S
End Connection: RTJ, BW, and Hub

Key Features:
Material Class: AA, BB, CC, DD, EE, FF, HH
Temperature Class: L, N, P, S, T, U, V, X, Y
Specification: PSL1 - PSL3G
Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2,000 PSI - 15,000 PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +400°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
