Underground Fully Welded Ball Valve, ASTM A105, DN500, PN40

Product Name: Underground/Buried Fully Welded Ball Valve
Design Standard: API 6D
Body Material: ASTM A105
Size: DN500, 20 Inch
Pressure: PN40, Class 300 LB
End Connection: BW
Operation: Manual

Fully Welded Ball Valve, also known as a Welded Body Ball Valve, features a fully welded construction for enhanced strength and durability. Designed for shutoff applications in water and gas supply systems, heat-power engineering, chemical processing, oil refining, and pulp and paper industries. Forged materials undergo ultrasonic examination per ASME non-destructive testing standards, with liquid penetration testing on the welding slope. The body wall includes a corrosion allowance for extended service life. The carbon steel stem, fixed shaft, ball, seat, and seat ring are chemically nickel-plated per ASTM B733 and B656, with additional corrosion-resistant material options. Valves can be customized to meet NACE MR 0175/ISO 15156 or NACE MR 0103 standards, ensuring reliability in sulfurization environments.

Technical Specifications

» Size Range: NPS 1/2-48 Inch (DN15-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: Carbon Steel, Stainless Steel, Duplex Steel
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» Seat Materials: RPTFE, DEVLON, PEEK
» Ends Connections: Flanged RF, RTJ, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A
» Temperature Range: -46°C to 120°C
» Medium: Water, Gas, Oil, etc.

Product Features

» Fully Welded Body Design
» Two-Piece or Three-Piece Body Construction
» Metal-to-Metal or Soft Sealing Options
» Full Bore or Reduced Bore Configuration
» Flanged or Welded End Connections
» Double Block and Bleed (DBB) Function
» Locking Device for Enhanced Security
» Single Piston Effect & Double Piston Effect Sealing
» Automatic Internal Body Pressure Relief
» Emergency Sealant Injection System
» Fire-Safe Design with Anti-Static Device
» Blowout-Proof Stem for Enhanced Safety
» Integrated Body Vent Device
» Suitable for Underground Installation
» Optional Extended Bonnet and Stem
» Leak-Free Body Joint Design for Environmental Protection
» Forged Steel Body Ensuring Fine Grain Structure and High Toughness
» Eliminating Common Casting Defects like Porosity and Gas Holes
