3600 WOG Ball Valve, 2-piece, ASTM A216 WCB, 3/4 Inch, NPT

Product Name: 3600 WOG Ball Valve, 2PC, Seal-Welded, FP
Body Material: ASTM A216 WCB
Size: 3/4 Inch, DN20
Pressure: 3600 WOG
End Connection: NPT Threaded
Operation: Lever
Medium: Water, Oil, Gas, etc
Temperature Range: -20°C to 150°C

The 3000 PSI high-pressure ball valve is a robust valve designed for high-pressure applications, offering exceptional durability and reliability. It is specifically engineered to handle demanding industrial processes, making it a preferred choice in industries such as petrochemicals, gas and oil, and hydraulics. This valve features a 3000 PSI pressure rating, ensuring it can withstand significant operational pressures. The body of the 3000 PSI internal thread ball valve is manufactured using a silica gel casting process, resulting in a structurally sound and aesthetically pleasing design. The valve seat employs an elastic sealing structure, providing reliable sealing performance and smooth operation. The valve rod features a bottom-mounted structure with an inverted seal, ensuring that it will not be ejected even if the valve chamber experiences abnormal pressurization.

Structural Features

» Configuration: 2-Piece Threaded, Full Port 1/4 to 2 Inches
» Construction: Seal Weld
» Body Material: ASTM A216 WCB
» Pressure Rating: 3000 CWP
» Corrosion Resistance: NACE MR-01-75 compliant
» Testing Standard: API 598
» Handle: Locking Device Handle
» End Connections: NPT Threaded Ends (comply with ANSI B1.20.1)
» Stem: Blowout Proof Stem
» Safety Feature: Anti-static Device
» Mounting Option: Mounting Pad

Structural Diagram

Materials of Main Parts

Main Dimensions (mm)
