22 Seats Commercial City Mini Bus

Name: China Manufacturers
Address: Room 2607, Meixin Plaza, No. 879 Xiahe Road, Siming District, Xiamen, CHINA
Telephone: 13276021100
Price range: $$$

Oct 09, 2020

Product name: Mini Bus, 22 Seats, Passenger Bus, Commercial City Bus.
Rated power: 80KW.
Max speed: 100km/h.
Fuel: Diesel.

Bus Parameters	Overall length（mm）	5995	Engine Paremeters	Engine model	JE493ZLQ4
	Overall width （mm）	2100		Engine manufacturer	JiangXi ISUZU
	Overall height （mm）	2640		Engine position/fuel	Front-mounted/diesel
	Wheel base （mm）	3300		Engine type	In line, 4 cylinders, Turbocharged medium cooling 、High pressure common rail
	Approaching and departure angle （º）	16/15		Power rating (kw)	80/3400
	Max. total mass (kg)	5500		Max. torque( N.m)	260
	Capacity (people/seats)	22+1		Displacement (ml)	2771
	Max. speed (km/h)	100		Emission standard	EURO IV
	Steering Orientaion	left hand driver
Item		Standard Specification			Attension
Base Paremeter	Transmission	Manual gearbox(GETRAG)
	Clutch	Diaphragm type clutch
	Front axle	Drum brake
	Rear axle	Drum brake
	Steering	Integral power steering
	Braking	ABS Oil brake, ABS
	Oil tank	70L
	Tire	7.00R16 Stainless steel wheel
	Body structure	Rectangular hollow section welded，Stamping parts
Bus Assembly	Interior trimming	Molding interior trim，Double longitudinal armrests plus front armrests
	Door & pump	Auto folding door
	Windscreen/side window	Sliding window
	Rear Assist Rearview system	Rearview mirror, inner view mirror
	A/C system	Inner air condition（10000kcal）
	Entertainment system	Radio with Mp3 ，back monitor ,CCTV system			CCTV (Customer Provided, MUDAN Installation )
	Wiper	wiper (with scrubber)
	Seats	22+1 seats, 5 seats with two point seat belts, no armrests, last 5 seats (Bench seats）,other passenger seats are 400MM
	Paint	Metallic Paint（golden）
	Other	Sun visor, aluminum thin floor ，Gray block floor leather, engine fire extinguisher, electronic clock，simple Front and back road signs(inside)，curtain，handrail with rings，no auto Sunroof，410mm steering wheel,Condenser elevated (no-load ground clearance 400mm)

The bus is up to 22+1 seats. With features like space of serenity, broad vision, comfortable seat, easier manipulation, from the moment you step on the vehicle gently, a pleasant journey also started. She is leading the new trend of high-end commercial vehicles.
