FTTH Fast Connector, SC, FC

Mar 27, 2015

Features
No-polished in factory.
Connector type: SC, FC.
Low insertion loss: <0.3dB.
High return loss: PC≥50dB, APC≥55Db.
High tensile strength: >20N.
Can be assembled easily and quickly.
Applied for FTTH, optical fiber cable quick-repaired.

Applications
FTTH.
Optical fiber cable quick-repair.

Specifications

Item	Technical Data
Cable type	900um, 2mm, 3mm fiber, 3.1mm×2.0mmbutterfly cable
Connector type	SC/APC, SC/UPC
Fiber dimension	125um( 652& 657)
Fiber type	Customer specified
Fiber mode	SM & MM
Insertion loss	Typ.:0.25dB, Max.:0.5dB(1310nm&1550nm)
Return loss	PC≥40dB APC≥55dB
Tensile strength	900um:＞4N,2mm/3mm:＞20N
Operating temperature	－40 °C~+85 °C
Temperature cycling	IL≤0.2dB, RL≤5dB
Vibration	IL≤0.2dB, RL≤5dB
Low Temperature Storage-40℃	IL≤0.2dB, RL≤5dB
85%H	IL≤0.2dB, RL≤5dB
