Pneumatic Closing Check Valve, WCB, DN600, PN16, CJ/T 282

Discover a Reliable Pneumatic Closing Check Valve Supplier. Our valves are crafted from high-quality ASTM A216 WCB material, available in DN600 (24 Inch) size, suitable for Class 150 LB and PN16 applications. Compliant with CJ/T 282 standards, our valves feature RF Flanged Ends in DN400 to DN900 range, accommodating PN6 to PN16 pressures.

Valve description:
Pneumatic Closing Check Valve, FLANGED
Design: CJ/T 282.
Body: ASTM A216 WCB
Nominal size: DN600.
Nominal class: PN16.
End Connection: RF flange.
Face to face: GB/T 12221.
Test and inspection: GB/T 13927.

Product Range:
Body material: ASTM A216 WCB.
Normal diameter: DN400 - DN900
End connection: Flanged.
Pressure range: PN6-PN16
Working temperature: ≤300°C.

Technical parameters and characteristics
Pneumatic Closing Check Valve

This Pneumatic Closing Check Valve is a three eccentric structure closing and slowly closing butterfly check valve with an auxiliary pneumatic device and slowly closing damping oil cylinder. It is applicable to the pipeline of air, combustible gas, water and other media with operating temperature < 300℃ and instantaneous temperature < 350℃. The opening of the valve is mainly realized by the pressure difference before and after the valve, while the closing of the valve depends on the dead weight of the valve clack and the action of the heavy hammer to automatically close most of the valve and the final closing is completed by the air pressure. The damping oil cylinder plays a buffering and damping role. Because of the three eccentric butterfly structures, the relative friction time of the valve clack in the opening and closing process is shortened, thus extending the service life and sealing performance of the valve. The damping oil cylinder can reduce the impact in the closing process eliminate the vibration caused by the pressure wave, and extend the service life of the valve.
