Stainless Steel Orbit Ball Valve
Key Specifications / Features
Stainless Steel Orbit Ball Valve Manufacturer in China: Stainless Steel Orbit Ball Valve, DN15-DN1200, Class 150-1500 LB, API 6D, ASME B16.34, MSS SP-72.
Request a quote
Detail Information
Construction is as follows:
The Stainless Steel Orbit Ball Valve are suitable for petrochemical, liquefied petroleum gas storage, oil refinery, natural gas, compressor system, oil and gas pipeline, light industry, textile and other industries.
Valve features:
1. Open and close without friction. This function completely solves the problem that the traditional valve is affected by the friction between the sealing surface and the sealing.
2. Jacket structure. The valve installed on the pipe can be checked and repaired directly. Can effectively reduce parking and reduce production cost.
3. Single seat design. It eliminates the problem that the medium cavity of the valve is affected by abnormal pressure.
4. Low torque design. Special structural design of the stem, only with a small hand wheel valve can easily open and close.
5. Wedge sealing structure. The valve is the mechanical force provided by the stem and the wedge is pressed to the seat and sealed. The sealing performance of the valve is not affected by the change of pipeline pressure difference, and the sealing performance is guaranteed under various working conditions.
6. Self-cleaning structure of sealing surface. When the ball tilting away from the seat, the pipeline flow experience along the sphere seal face into evenly through 360°. It not only eliminates the flushing of the high speed fluid to the seat, but also washes away the accumulated material on the sealing surface to achieve self-cleaning purposes.
| Name | Worm Gear Carbon Steel Top Entry Orbit Ball Valve. |
| Size | DN15-DN1200. |
| Normal pressure | Class 150, 300, 600, 900, 1500 LB, PN16, PN40, PN64, PN100, PN160. |
| Material | ASTM A216 WCB, ASTM A105, ASTM A352 LCB, ASTM A350 LF2, ASTM A351 CF8, ASTM A351 CF8M, ASTM A182 F304, ASTM A182 F316. |
| Design standard | API 6D, API 608, ASME B16.34, MSS SP-72, BS 5351, ISO 17292, EN 13709. |
| Marked | MSS SP-25. |
| Fire safe design | API 607, API 6FA. |
| End flange | ANSI B16.5, ASME B16.47, EN 1092, DIN 2543-DIN 2547, AS 2129. |
| Face to Face | ANSI B16.10, API 6D, DIN 3202, EN 558-1, EN 12982, ISO 5752. |
| Top flange | ISO 5211. |
| Test standard | API 598, API 6D, DIN 3230, EN 12266, ISO 5208. |
| Suitable temperature | -10 - 200℃. |
| Medium | Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc. |
| Acidic environment | NACE MR0175. |
| Operation | Hand Operated,Gear Operated, Electrical Actuated, Pheumatic Actuated. |
The Stainless Steel Orbit Ball Valve are suitable for petrochemical, liquefied petroleum gas storage, oil refinery, natural gas, compressor system, oil and gas pipeline, light industry, textile and other industries.
Valve features:
1. Open and close without friction. This function completely solves the problem that the traditional valve is affected by the friction between the sealing surface and the sealing.
2. Jacket structure. The valve installed on the pipe can be checked and repaired directly. Can effectively reduce parking and reduce production cost.
3. Single seat design. It eliminates the problem that the medium cavity of the valve is affected by abnormal pressure.
4. Low torque design. Special structural design of the stem, only with a small hand wheel valve can easily open and close.
5. Wedge sealing structure. The valve is the mechanical force provided by the stem and the wedge is pressed to the seat and sealed. The sealing performance of the valve is not affected by the change of pipeline pressure difference, and the sealing performance is guaranteed under various working conditions.
6. Self-cleaning structure of sealing surface. When the ball tilting away from the seat, the pipeline flow experience along the sphere seal face into evenly through 360°. It not only eliminates the flushing of the high speed fluid to the seat, but also washes away the accumulated material on the sealing surface to achieve self-cleaning purposes.
