API 6D Fully Welded Ball Valve, 2–60 Inch, 150–2500 LB
Key Specifications / Features
API 6D Fully Welded Ball Valve Maker: Fully Welded, Ball Valve, API 6D, A105, LF2, F11, F51, F55, 2–60 Inch, 150–2500 LB, NPT, BW, RF, RTJ, API 608, ASME B16.34.
Request a quote
Detail Information
Carbon Steel Fully Welded Ball Valve (All-welded ball valve) purpose:
1) Urban gas: gas output pipeline, main line and supply pipeline of each branch line, etc.
2) Central heating: output pipeline, main line and branch line of large heating equipment.
3) Heat exchanger: pipe and circuit opening and closing.
4) Steel works: all kinds of fluid pipelines, exhaust gas selection pipes, gas and thermal supply pipelines, fuel supply pipelines.
5) Various industrial equipment, various heat treatment pipes, various industrial gas and thermal pipelines.
Valve Size: 2 Inch–60 Inch, DN50–DN1200.
Pressure Class: Class 150–2500 LB, PN16–DN420, JIS 10-20 K.
Materials: ASTM A105, ASTM A350 LF2, ASTM A182 F316, ASTM A182 F11, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F55.
Design and Manufacturing Standards: API 6D, API 608, ASME B16.34, ISO 17292, BS 5351.
Face to Face Standards: ASME B16.10, BS 558, BS 12982, ISO 5752.
Flange Dimension Standards: ASME B16.5, ASME B16.47, ASME B16.25, ASME B16.11, BS 12627.
Pressure Test Standards: API 598, API 6D, BS 12569.
Fire Safety Test Standards: API 6FA, API 607.
Quality/Product Certifications: ISO 9001, ISO 14001, ISO 18001.
Fugitive Emissions: ISO 15848-1, API 622.
NACE: NACE MR 0175.
Valve operator options: Hand wheel, Worm Gear, Electric actuator, Pneumatic actuator, Hydraulic Actuator.
Shutoff Class: API 598 (Zero Leakage), API 6D.
Bore: Full Bore, Reduced Bore.
Process Connection Types: SW, NPT, BW, RF, RTJ.
Full welding ball valve performance:
1) No maintenance, adjustment and lubrication, easy to install and reliable operation under low operating expenses. The surface adopts the spray-plastic treatment technology so that it is shiny, in the country already at the leading level. There will be no external leakage. The valve body is welded, so the valve is light and easy to insulate. It is very simple to install the adjustment mechanism. The handle can be removed and reverse installation can be adopted.
2) Because the seat is made from carbon fibre reinforced teflon seal ring and disc spring, so the ability to adapt to the change of pressure and temperature.
3) The ball machining process is tracked and detected by an advanced computer detector, so the machining accuracy of the ball is high.
4) As the body material is the same as the pipe material, there will be no uneven stress and deformation due to the earthquake and the vehicle passing through the ground. The pipeline is resistant to aging.
5) Integral whole welding, equal diameter and variable diameter channel, with the fixed ball or floating ball, double piston effect sealing system and automatic sealant injection bearing.
6) In order to prevent static electricity, stem and sphere and valve stem and packing box with a ball and spring respectively, which can keep the conductivity between all parts of the valve and the valve body, and let the current pass through the area and release static electricity, preventing fire and corrosion, and realizing temporary cut-off for timely repair.
7) The stem has the function of preventing falling off. Because the valve stem is affected by the pressure inside the valve, and it always produces a disconnection force, so it is designed as an anti-falling structure.
The thrust washer with low friction material is used to push the pressure to the valve stem, so that the stem can only transmit torque.
1) Urban gas: gas output pipeline, main line and supply pipeline of each branch line, etc.
2) Central heating: output pipeline, main line and branch line of large heating equipment.
3) Heat exchanger: pipe and circuit opening and closing.
4) Steel works: all kinds of fluid pipelines, exhaust gas selection pipes, gas and thermal supply pipelines, fuel supply pipelines.
5) Various industrial equipment, various heat treatment pipes, various industrial gas and thermal pipelines.
Valve Size: 2 Inch–60 Inch, DN50–DN1200.
Pressure Class: Class 150–2500 LB, PN16–DN420, JIS 10-20 K.
Materials: ASTM A105, ASTM A350 LF2, ASTM A182 F316, ASTM A182 F11, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F55.
Design and Manufacturing Standards: API 6D, API 608, ASME B16.34, ISO 17292, BS 5351.
Face to Face Standards: ASME B16.10, BS 558, BS 12982, ISO 5752.
Flange Dimension Standards: ASME B16.5, ASME B16.47, ASME B16.25, ASME B16.11, BS 12627.
Pressure Test Standards: API 598, API 6D, BS 12569.
Fire Safety Test Standards: API 6FA, API 607.
Quality/Product Certifications: ISO 9001, ISO 14001, ISO 18001.
Fugitive Emissions: ISO 15848-1, API 622.
NACE: NACE MR 0175.
Valve operator options: Hand wheel, Worm Gear, Electric actuator, Pneumatic actuator, Hydraulic Actuator.
Shutoff Class: API 598 (Zero Leakage), API 6D.
Bore: Full Bore, Reduced Bore.
Process Connection Types: SW, NPT, BW, RF, RTJ.
Full welding ball valve performance:
1) No maintenance, adjustment and lubrication, easy to install and reliable operation under low operating expenses. The surface adopts the spray-plastic treatment technology so that it is shiny, in the country already at the leading level. There will be no external leakage. The valve body is welded, so the valve is light and easy to insulate. It is very simple to install the adjustment mechanism. The handle can be removed and reverse installation can be adopted.
2) Because the seat is made from carbon fibre reinforced teflon seal ring and disc spring, so the ability to adapt to the change of pressure and temperature.
3) The ball machining process is tracked and detected by an advanced computer detector, so the machining accuracy of the ball is high.
4) As the body material is the same as the pipe material, there will be no uneven stress and deformation due to the earthquake and the vehicle passing through the ground. The pipeline is resistant to aging.
5) Integral whole welding, equal diameter and variable diameter channel, with the fixed ball or floating ball, double piston effect sealing system and automatic sealant injection bearing.
6) In order to prevent static electricity, stem and sphere and valve stem and packing box with a ball and spring respectively, which can keep the conductivity between all parts of the valve and the valve body, and let the current pass through the area and release static electricity, preventing fire and corrosion, and realizing temporary cut-off for timely repair.
7) The stem has the function of preventing falling off. Because the valve stem is affected by the pressure inside the valve, and it always produces a disconnection force, so it is designed as an anti-falling structure.
The thrust washer with low friction material is used to push the pressure to the valve stem, so that the stem can only transmit torque.
