Vertical Canned Centrifugal Pump, DN40-DN300, 8-125 m Head

Product Name: PBG Vertical Canned Motor Centrifugal Pump
Product Type: Canned Centrifugal Pump
Diameter: DN40-DN300
Head: 8-125 m
Flow: 4-750 m3/h
Speed: 1450-2900 r/min
Motor Power: 0.37-132 KW
Working Temperature: -20°C to 160°C
Other: The voltage is optional as required by the customer

Vertical Centrifugal Pump Description

The PBG-type Shielded Pipeline Pump is designed using advanced international shielding technology, ensuring high performance in fluid transport applications. With features that comply with ISO 2858 international standards, as well as national and industry-specific standards, this pump is a cutting-edge solution for vertical pipe installations. It is characterized by its stable performance, low noise, and minimal vibration, making it a superior alternative to conventional horizontal centrifugal pumps. The pump is available in a variety of configurations, offering a flow range from 6.3 to 1080 m³/h and heads from 12.5 to 125 meters. It is powered by motors ranging from 0.37 to 160 kW and operates at speeds of 1450 and 2900 rpm.

Vertical Centrifugal Pump Applications

» General Use: Suitable for transporting water and liquids with physical and chemical properties similar to water, at temperatures up to 80°C. It is ideal for industrial and urban water supply and drainage, high-rise building pressurization, garden irrigation, fire boosting, HVAC refrigeration cycles, and bathroom heating and cooling equipment.

» Hot Water Applications: Used for transferring soft water (without solid particles) at temperatures up to 160°C in energy, metallurgy, chemical, textile, paper, hotel, restaurant, and urban heating systems.

» Anticorrosive and Particle Handling: Designed for transporting solid particles and corrosive liquids, commonly applied in petroleum, chemical, metallurgy, power generation, paper, food, pharmaceutical, and synthetic fiber industries.

Vertical Centrifugal Pump Features

» Compact and Space-Efficient: The pump’s integrated design and small size result in a vertical structure that takes up minimal space, making installation straightforward with no need for additional adjustments.

» Coaxial Design: The motor and pump are designed to be coaxial, minimizing axial dimensions and ensuring smoother operation with reduced noise.

» Leak-Proof: The PBG-type pump eliminates the need for conventional shaft seals, ensuring that there is no medium leakage during operation.

» Low Vibration and Noise: Replacing conventional rolling bearings with sliding bearings minimizes vibration and noise, providing smooth and quiet performance.

» Easy Installation and Maintenance: The pump’s design allows for simple installation and maintenance, as rotor components can be inspected and repaired by removing only the connecting nut, without needing to open the entire pipeline system.

» Flexible Operation: The pump can be operated in series or parallel, depending on the specific flow and head requirements, to meet varying system demands.
