ASTM A182 F51 DBB Ball Valve, API 6D, 12*10 IN, CL1500, RTJ

The ASTM A182 F51 Ball Valve Supplier offers high-quality double block and bleed ball valves designed to meet API 6D standards. These valves feature a duplex stainless steel body made from ASTM A182 F51, providing excellent corrosion resistance and durability. Available in a size combination of 12 inches by 10 inches (DN300 by DN250), they operate at a pressure rating of Class 1500 LB and PN250. The valves come with ring-type joint (RTJ) ends for secure and reliable connections.

Product Name: Double Block and Bleed (DBB) Ball Valve
Design Standard: API 6D
Body Material: ASTM A182 F51
Size: 12*10 Inch, DN300*DN250
Pressure: Class 1500 LB, PN250
End Connection: RTJ
Operation: Gear Box

Double Block and Bleed (DBB) Valves are engineered for double isolation functionality, achieved by inserting two obturators within a single body. The valves feature a bleed/vent system positioned between the obturators (such as the body port and ball, gate, or needle valve), offering enhanced safety and reliability. This design enables the isolation of a pipeline section from both sides of the valve, ensuring secure shutoff and minimizing the risk of leaks, making it ideal for high-risk industries like oil and gas. The DBB ball valves help reduce the need for additional valves, optimizing both space and cost efficiency while maintaining strong security and operational safety.

Technical Specifications

» Size Range: NPS 1/2-2 Inch (DN15-DN50)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: Forged Carbon Steel, Stainless Steel, Duplex, or Special Alloys (ASTM A105N, A350 LF2, A182 F11, F22, F304, F304L, F316, F316L)
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» End Connections: RF and FTJ Flanged
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Temperature Range: -46°C to 350°C
» Medium: Water, Gas, Oil
» Standards
   Design and Manufacture: API 6D, BS 5351, ASME B16.34
   Face-to-Face Dimensions(end to end): Manufacturer's standard
   Flanged Connections: ASME B16.5
   Test and Inspection: EEMUA 182, API 598
   Threaded Ends: ASME B1.20.1
   Fire Safety: API 607, API 6A

Product Features

» DBB integrated body utilizes a dual type construction
» Side entry forged steel valves
» Top-entry design available upon request
» Low pressure loss through the valve for efficient flow control
» Low actuation torque for easy operation
» Full bore or reduced bore options
» Materials with anti-corrosion properties in compliance with NACE MR 0175
» Metal-sealed seat pocket area overlay or cladding on wetted surfaces (with welded overlays in Inconel 625, Stainless Steel 316, or Electroless Nickel Plating) for enhanced durability and corrosion resistance
