ASTM A182 F22 Y Globe Valves, API 602, 3/4 Inch, CL2680, PSB

The ASTM A182 F22 Y Globe Valves Manufacturer specializes in producing high-pressure Y globe valves with a pressure seal bonnet design. These valves are made from forged stainless steel, ensuring durability and resistance to high pressures. They comply with API 602 standards and have a 3/4 inch (DN20) size with a pressure rating up to Class 2680 LB. The valves feature butt weld ends for secure and reliable connections.

Product Name: ASTM A182 F22 Y Globe Valves, Pressure Seal Bonnet
Type: Y Type Globe Valve
Design Standard: API 602
Body Material: ASTM A182 F22
Size: 3/4 Inch, DN20
Pressure: Class 2680 LB
End Connection: BW
Operation: Manual
Medium: Water, Oil, Gas, etc
Temperature Range: -29°C to 595°C

Pressure Seal Globe Valves are engineered and manufactured in strict accordance with international standards including API 602, ASME B16.34, DIN 3202, or their equivalents. Featuring a compact yet robust design, these valves are optimized for high pressure and temperature applications. An optional solid CoCr alloy wedge ensures low friction and extended service life. Packing rings are precompressed to 4000 psi, providing a high-integrity, reliable seal.
For welded bonnet valves, the bonnet is threaded and tightened to a precisely engineered torque value, with the body-bonnet joint strength-welded, offering dual protection against leakage. The fully guided wedge design minimizes wear on seating surfaces. Additional optional features include double packing, leak-off connections, live-loading, and packing blowout for straightforward removal and replacement of packing materials.

Technical Specifications

» Type: Pressure Seal Globe Valve
» Size Range: 1/2-2 Inch (Forged items)
» Design Pressure: Class 900 - 2500 LB (PN160-PN420)
» Materials: Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, and other custom alloys
» Trim Materials: 13% Cr, ASTM A182 F11, F22, SS 304, SS 304L, SS 316, SS 316L, and other special alloys
» End Connections: Socket Weld (SW), Butt Weld (BW), Ring Type Joint (RTJ) Flange
» Design & Manufacture Standards: ASME B16.34, API 602
» Face-to-Face (End-to-End): ANSI B16.10
» Flanged Connections: ANSI B16.5
» Testing & Inspection: API 598, API 6D
» Butt Weld Ends: ANSI B16.5
» Socket Weld Ends: ASME B16.11

Product Features

» Manufactured from forged steel with precision machining, providing excellent corrosion resistance suitable for a wide range of corrosive media, significantly extending valve service life.
» Compact forged steel design results in reduced valve size and weight, minimizing installation space requirements and facilitating use in confined environments.
» Fully guided wedge design reduces wear and prolongs seat life, ensuring reliable performance in demanding conditions.
» Optional features such as double packing, leak-off connections, live-loading, and packing blowout provide enhanced sealing integrity and ease of maintenance.
