Non-brittle Ceramic Fiber Vacuum Shapes

Name: Non-brittle Ceramic Fiber Vacuum Shapes
SKU: SPE-CGYXJ
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

China Ceramic Fiber Vacuum Shapes Super Manufacturer: Non-brittle Ceramic Fiber Vacuum Shapes, Excellent Thermal Shock Resistance, Long Service Life.

Request a quote

Detail Information

Model: SPE-CGYXJ.

Characteristics:

Super ceramic fiber vacuum-shaped products are manufactured by Super ceramic fiber bulk with inorganic bond and little organic bond through vacuum formed technics.The vacuum formed products are used to satisfy fire-resistance and heat insulation of the special parts of the heating process equipment. The products are non-brittle materials and have high intensity, accurate dimension and can be made according to demand of clients. Moreover, they can directly contact flame with their good fire-resistance and heat insulation. In the process of heating application, the organic binder will be volatilized at the temperature 250-350℃, after volatilization, the product is pure white.

The classification temperature(℃): 1260/1360/1450.

* Good toughness, resistance to erosion and thermal shock.

* Contact flame directly.

* Low thermal conductivity and heat storage.

* Easy to machine,complex shapes.

Applications:

* Burner and door of industry furnace.

* Riser sleeves for ferrous and non ferrous melten metals.

* Furnace sight holes, duct and flue linings.

* Heat element support.

* Hot tops, roller insulation, gasket, hot gas filtering.

Technical Index:

Type		SPE-CGYXJ
Classification Temperature ℃		1260	1360	1450
Operation Temperature ℃		≤1000	＜1200	≤1350
Density Kg/m3		300/400/500
Permanent Linear Shrinkage ％ 300 Kg/m3		1000℃X24H≤-2	1200℃X24H≤-2	1350℃X24H≤-2
Thermal Conductivity （w/m.k）	600℃	0.086-0.087	0.083-0.085	0.083-0.085
	800℃	0.106-0.108	0.101-0.105	0.101-0.105
Size（mm）		Make as customers’ drawings
Packing		Carton
Quality Certificate		ISO9001-2000 GBT 3003-2006 MSDS
