Flexible Wedge Gate Valves, API 600, A351 CF8, 3 IN, CL150

Product Name: Flexible Wedge Gate Valve
Features: OS&Y, Metal Sealed
Design Standard: API 600
Body Material: ASTM A351 CF8
Size: 3 Inch, DN80
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Handwheel

Our Cast Steel Gate Valves are engineered to achieve a VOC leakage of less than 100 ppm (parts per million). Extensive baseline laboratory tests, including both static and cycle testing, have been conducted to establish the critical design parameters needed for effective low-emission sealing in the stem packing and bonnet gasket areas. A dedicated in-house testing procedure is regularly performed to verify that the valve's design and manufacturing standards consistently ensure that each KOSEN Cast Steel Gate Valve meets the 100 ppm VOC leakage limit before shipment.

Technical Specifications

» Nominal Diameter: NPS 1/2-48 Inch (DN15-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3M, CF8C, CN3MN, CK3MCUN, CN7M, A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN), B148 C95800, C95500
» End Connections: Flanged (FF, RF, RTJ) to international standards
» Operation: Hand wheel, bevel gear, electric, pneumatic
» Design and Manufacture: ANSI B16.34, API 600, API 6D, API 603, BS 1414
» Face to Face (End to End): ANSI B16.10, API 6D
» Flanged Connection: 2-24 Inch to ANSI B16.5, 22 Inch, 26-36 Inch to MSS-SP-44 or to API 605 on request
» Test and Inspection: API 598, API 6D
» Butt Welded End: ANSI B16.25
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, etc.

Product Features

» Anti-Friction Ball Thrust Bearing: Reducing friction between mating parts to ensure smooth operation.
» Grub Screw: Securing the yoke nut in the bonnet.
» Grease Nipple: Supplying lubricant to the mating parts.
» OS&Y (Outside Stem and Yoke): Providing easy access to the stem and yoke for maintenance.
» Metal-Sealed: Available in API Trim #1, #5, #8, #10, and more.
» Optional Locking Device or Stem Extension: Enhancing security and accessibility.
» Optional Direct Mounting to ISO 5211: Compatible with industry-standard mounting.
» Full Port: Ensuring maximum flow capacity.
