API 609 Double Offset Butterfly Valve, Titanium, 30IN, 300 LB

Dec 15, 2024

On this page

RPTFE Seated Butterfly Valve, Double Offset, 30 Inch/DN750, Class 300 LB, Gear Operation.

Valve Description

A double offset butterfly valve is extensively used in pipelines for isolation and flow regulation, particularly in applications that demand frequent opening and closing.

1862153 High-Performance Butterfly Valve
Design Standard:	API 609 Category B, EN 593
Structure:	Double Offset, Double Eccentric
Body Material:	Titanium, ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M.
Nominal Size:	30 Inch, DN750
Nominal Class:	Class 300 LB, PN50
Seat Type:	Soft Seat
Test and Inspection:	API 598, API 609
Trim Material:	ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Face to Face:	API 609, EN 593
Operation:	Gear
Seat:	RPTFE, PPL
End Connection:	Double Flanged
Key Features:	Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
