Segmented Ball Control Valve, DN80, PN16, ASTM A351 CF8/CF8M

Product Description

Product Name: Segmented Ball Control Valves
Size Range: DN25-DN500
Body Material: ASTM A351 CF8, CF8M, ASTM A216 WCB
Actuator Connection: ISO 5211
Technical Features:
Working Pressure: PN16, PN25, PN40, Class 150 LB, 300 LB, 600 LB
Certificate: ISO 9001 & CE Accredited
Flange Type:
Face to Face: ISA S75.04, IEC/DIN 534-3-2
Seal Tightness:
Metal Seat: Class V (standard), Class VI (with Tungsten Carbide Coated Trim)
Soft Conta: Class VI
Valve Trim Rotation: Clockwise to close
Flow Characteristic: Equal Percentage
Application: Pulp and paper, waste water treatment, food and beverage, chemical plants, power plants, steel industry, etc.











Dimensions
